Product Description
Galaxy Audio AS-1206-2* 1200 Series Twin Pack WPM With EB6
Reduce stage volume, avoid cumbersome stage monitors, and eliminate needless wire clutter with Galaxy Audio’s new AS-1200 Wireless Personal In-ear monitors. The AS-1200 lets you enjoy freedom of movement with a range of up to 300ft. The 210 selectable UHF frequencies offer stereo monitoring and dependable performance even in challenging RF environments. The Galaxy Audio AS-1200 Wireless Personal In-ear monitors sends your mix directly to your ears while isolating stage noise, resulting in a more accurate and precise representation of your music regardless of your position on stage. The AS-1200 is built on the same trusted and reliable wireless in-ear platform Galaxy Audio has been providing musicians for decades.
The AS-1200R receiver offers a backlit LCD display with Lock, Channel Number, Stereo, Mono, Frequency, RF/AF Level and 4 Bar Battery Indicator, plus an RF and Stereo indicator LED on top of the body pack. Featuring 100mW stereo output, the AS-1200R delivers more than enough gain for any live stage performance. The included EB4 ear buds feature titanium drivers, extended bass response and aluminum alloy construction. Upgrade to Galaxy Audio EB6 or EB10 ear buds or use your custom fit or favorite set of ear buds. The AS-1200 accepts all ear buds that utilize the 1/8- inch (3.5 mm) stereo headphone jack.
The AS-1200T transmitter incorporates a backlit LCD that displays lock on/off, L/R AF levels, group/channel, frequency number, and mono/stereo mode. AS-1200T front controls include a settings button, up/down select buttons, and volume control for the front facing headphone output. The back panel features line level right and left XLR/1/4″ combo inputs and right/left AF level controls. A Single/Dual Rack mount kit and a BNC antenna is included.
Available options include the AS-1200-2 Twin Pack with two receivers and one transmitter or the AS-1200-4 Band Pack system with four receivers and one transmitter, providing multiple performers a shared monitor mix.
AS-1200 System Features
- 210 Selectable UHF Frequencies
- Backlit LCD (Displays Group, Channel Number, Stereo, Mono, Frequency and Right, Left AF Level, Lock)
- Multiple Receivers can be used with 1 Transmitter
- Stereo or Mono Transmission
- Single/Dual Rack Mount Kit Included
- 300′ Range
- EB4 Ear Buds Included
- An unlimited number of receivers may be added at any time.
AS-1200T Transmitter
- 210 Selectable UHF Frequencies
- Transmits in Stereo or Mono
- Backlit LCD Display (Displays Group, Channel, Frequency, Stereo, Mono, Right/Left AF Level, and Lock)
- Line Level x 2-XLR/¼” Combo Jacks
- AF L/R Indicator
- RF Output 10 mW
- Detachable BNC Antenna Included
AS-1200R Receiver
- Built-in Limiter
- >65 mW x 2 Earphone Output with Volume Control
- Backlit LCD Display (Displays Group, Channel, Frequency, Stereo, Mono, 4 Bar Battery Indicator, RF/AF Level, and Lock)
- 4 Bar Battery Life Indicator
- RF and Stereo Indicators
- Output Connector 1/8” (3.5mm) Stereo
- EB4 Ear Buds Included
- Powered by 2 AA Batteries Alkaline or Rechargeable
- 3.2 oz (90 g)
210 selectable channels, includes 1 AS-1200T, 1 AS-1200R, EB6 ear buds, single/dual rack kit, antenna, and power supply.
Additional products in this configuration:
- EB6
The EB6 features a single driver delivering full frequency performance. The Galaxy Audio EB6 has a cable over 4 feet long and the earbuds weigh 6g (less than 0.25 oz; excluding cable). The EB6 in-ear wired single driver earphones include a durable plastic carrying case with three pairs of Silicon Sleeves (small, medium and large).
- Wideband Dyna Driver earbuds reproduce the full frequency range with natural mids, full highs, and rich bass.
- They allow musicians to monitor their mix with full detail.
- Three different sized pairs of silicon sleeves are provided for best fit and sound isolation.
- Ergonomic mechanical structure ensures long time, low fatigue use.
SPECIFICATIONS
| Frequency Response: | 20Hz~20 kHz |
|---|---|
| Transducer Type: | Dynamic |
| Impedance: | 16 Ohms |
| Sensitivity: | (@ 1 kHz) 114 dB/mW |
| Distortion: | Less than 0.3% |
| Cord Length: | Over 4 & ½ Foot 58" (148cm) with Ø1/8" (3.5mm) stereo plug |
| Accessories: | Three pairs of Silicon Sleeves (small, medium, and large),Acrylic Case |
| Weight: | 0.25oz. (6g) (excluding cable) |
