Product Description
Exalux LMA.001.012- EXA LEDMASTER NEO LED Dimmer
Overview
EXALUX™ LEDMASTER NEO is a constant voltage LED dimmer designed to power LED fixtures on film sets.
Thanks to its high output capacity, LEDMASTER NEO allows to softly drive 480W of LED light (@24VDC).
LEDMASTER NEO is really ideal for dimming LED panels with a high output lumens.
The two individual outputs can be used in a different way:
> Tunable White Sync mode: both outputs operate simultaneously (240W+240W),
> Tunable White Dual mode: both outputs operate individually (240W+240W),
> Dual Channel: only one output is used at full power (480W).
Features
- 4 independent channels, 480W Power Rating,
- Manual / Remote control,
- Built-In DMX/RDM 512 decoder,
- Built-In CRMX / RDM Receiver,
- 2000K>7000K patented CCT synthesizer,
- 3 operating modes: Tunable White / Dual Channel / Special FX,
- Master /Slave Operation,
- 4 CCT presets (3200K, 4300K, 5000K, 5600K)
Specifications
| Power Rating | Out A : 240W |
| Out B : 240W | |
| Out A+Out B : 240W+240W | |
| Output Voltage | 24VDC PWM |
| Current load | Up to 20A (up to 10A per channel) |
| Trigger Input | Jack 2.5mm |
| Housing / Mounting | Aluminium, black painting |
| Protection | Shortcircuit / Overcurrent (Internal Fuse) |
| Certifications | CE, RoHS |
| Weight | 670g |
DMX INTERFACE
| Protocol | DMX512-A |
| RDM ANSI E1.20 | |
| Universe support | 1 |
| DMX frame rate | 0,8-830Hz |
| End to end latency | < 5ms |
| DMX Input | Neutrik XLR 5 pins Female |
| DMX Output | Neutrik XLR 5 pins Male |
RADIO INTERFACE
| Standard / Technology | LumenRadio CRMX™ |
| Frequency | 2.402 ~ 2.480 GHz |
| Antenna | Omnidirectional |
| 2.4GHZ 2.0dBi, SMA | |
| RF Output | 20 dBm (100mW) |
| RF Modulation | GFSK |
| Range | Up to 300m |
| (depending on the transmitter and the environment) |
OPERATING CONDITIONS
| DC Input | XLR 4 INPUT |
| 24VDC | |
| Storage T° | Min : -30°C | Typ : 25°C | Max : +80°C |
| Operating T° | Min : -20°C | Typ : 25°C | Max : +70°C |
