Product Description
Exalux CNT.000.002- EXA CONNECT ONE Wi-Fi to DMX Converter (Starter Kit)
Overview
The CONNECT ONE Wi-Fi to DMX Converter Starter Kit from Exalux features integrated Wi-Fi and Art-Net/DMX interfaces, so it works without an extra access point required. It is versatile and suitable for use in a broadcast studio using AC power or on the field using battery power, thanks to its wide-range power mode. Switching from one power supply to another does not disconnect the Wi-Fi connection.
The CONNECT ONE is easily operated with free-to-download iOS or Android apps, providing precision control from a tablet or smartphone. It interfaces perfectly with all DMX applications based on the Art-Net protocol, such as BlackOut, Luminaire, and more.
Starter Kit Contents
- CONNECT ONE wireless gateway
- D-Tap to female 4-pin XLR female power cable
- USB-A to female 4-pin XLR power cable
- 5-pin XLR female to male extension cable
- USB-A to micro-USB cable
- 5.0 VDC, 2200mAh power bank
- Carrying case
Specifications
General
| Inputs/Outputs | 1 x XLR 5-Pin (DMX) Locking Male Output 1 x XLR 4-Pin (Power) Male Input 1 x 3-Pin (Power) powerCON Male Input |
| Channels | 512 (DMX) |
| Cooling System | Passive |
| Frame Rates | 0.8 to 830 Hz |
| Latency | 5 ms |
| Wireless Range | 328.1' / 100 m |
| Frequency | 2.4 to 2.48 GHz |
| Antenna Gain | 20 dBi (External) |
| Transmit Power | 17.5 dBm |
Power
| Power Consumption | 1.0 W |
| AC Input Power | 85 to 264 VAC, 50 / 60 Hz |
| DC Input Power | 4.5 to 24 VDC |
Compatibility
| Protocol | DMX512 |
| Mobile Operating System Support | iOS Android |
Environmental
| Operating Temperature | -4 to 158°F / -20 to 70°C |
| Storage Temperature | -22 to 176°F / -30 to 80°C |
| Certifications | CE, RoHS *as per Manufacturer |
| IP Rating | IP20 |
| Environmental Protection | Advertised as Dust Resistant *Manufacturer Testing: IP20 |
Physical
| Material of Construction | Aluminum |
| Dimensions | 5.6 x 1.9 x 5.7" / 141.0 x 47.0 x 144.0 mm (Without Antenna) 5.6 x 1.9 x 8.8" / 141.0 x 47.0 x 224.0 mm (Including Antenna) |
| Weight | 12.5 oz / 355 g |
