Product Description
ETC UHFI-8-WM Unison Fader Interface - Wall-Mount Wired
Overview
The Unison Heritage Fader Interface provides a convenient variable level interface to external devices via a variable 0–3.3 V analog signal, sourced by the interface. The Fader Interface provides eight input connections functionally coupled to eight lamp-driver connections, providing up to 100 mA at 24 VDC.
Features
- Designed for use with Unison Paradigm Control Systems
- LinkConnect – using Echelon® LonTalk® protocol with LinkPower, the two wire topology-free system gives you the freedom to put the Fader Interface where you need it.
- Zone, Master, or Fade Time control functions assigned in software
- Terminals for all wire connections
- Custom configurations available
- External lamp driver
