ETC UFMP8 8 Zone DMX Mini Panel
Foundry is a line of DMX-controlled distributed power control products that includes Mini Panels, Relay Controllers, 0-10V Controllers, and Phase-adaptive Dimmers. Foundry products are the perfect partners for Unison Paradigm, Mosaic or any third-party DMX control system, helping users create complete lighting and plug-load control packages that provide advanced energy saving features and meet stringent energy code.
Adding power to lighting control
DMX-controlled Unison Foundry™ products are the perfect partners for Unison Paradigm® and Mosaic® systems to create a complete, economical lighting control package. The Foundry Mini Panel takes 20A branch circuit input and provides four or eight switched power control outputs with fully-isolated 0-10V dimming per output.
The Foundry Mini Panel comes in two versions—a four input/four output or an eight input/eight output model—and each version can be configured in multiple ways. Each Mini Panel can be wired with discrete inputs for each output, just one input split to all outputs, or anything in between. With the capacity to support combinations of 120V, 277V, normal and emergency circuits in a single Mini Panel, Foundry offers outstanding flexibility in a compact, robust package.
Responds to your demands
When partnered with the responsive controls of a Unison Paradigm system, Foundry can modulate power use via a Demand Response input to ensure a building meets energy codes. Maximum output per zone is simply contractor-configured right at the Mini Panel.
Foundry Mini Panels are a new addition to ETC’s unparalleled line of emergency lighting controllers. With both a branch circuit sense feed input and a dry contact input for UL924-listed triggering of emergency lighting control bypass, the Mini Panel immediately drives power and 0-10V control on for emergency lights while providing the option for load shedding control to power down normal loads at the same time.
Product Features
|
The Foundry Mini Panels offer up to eight zones of DMX controlled lighting with fully rated 20 Amp relays and optional 0-10V control per zone. The Mini Panel features a Demand Response input for energy saving integration and a UL924 emergency lighting control bypass with power loss sense. The Mini Panel is wall-mounted and plenum rated to be easily tucked out of sight.
APPLICATIONS • Arena and stadium suites • Office buildings • Conference and meeting rooms • Healthcare facilities • Houses of worship • Classrooms • Hospitality and restaurants • Retail
FEATURES • Switched power control of four or eight circuits with 0-10V dimming • 120 or 277VAC power input per zone • 20 Amp fully rated relays for use with general purpose, tungsten, fluorescent, LED and plug loads • 0-10V dimming output per zone for direct connection to dimming ballasts and LED drivers • Demand Response load shedding contact input • UL924 control bypass via - Contact closure input - Normal power loss sense feed terminals • DMX controlled and RDM configurable
GENERAL • UL, cUL and UL924 LISTED • Rated for plenum installation • Suitable for plug load control
SPECIFICATIONS
FUNCTIONAL • Control for up to eight zones of switching for lighting and plug loads • Control for up to eight zones of 0-10V dimming for LED drivers and fluorescent ballasts • UL924 emergency-lighting control via contact closure and power loss sense feed terminal • Demand Response input provided by a power company can enforce a maximum level per circuit while active • Supports USITT DMX512-A (ANSI E1.11) • Supports RDM (ANSI E1.20)
MECHANICAL • Constructed of 16-gauge cold-rolled steel, finished in fine-textured, black powder coat • Wall-mount installation; - rated for installation in plenum air space • Class-1 voltage barrier prevents access to line-voltage wiring with front panel removed • Optional voltage divider allows for separation of normal and emergency circuits in a single controller where allowed by local codes
ELECTRICAL • 100-277V, 50/60Hz power input per circuit with support for pass thou to multiple circuits • Supports 120V and 277V circuits within the same panel • 20-Amp, fully-rated bi-state latching relay per output • 0-10VDC control rated for up to 100mA sink per output - 0-10V outputs are fully isolated from ground to 2500V RMS • Rising clamp screw terminal wiring connections for: - Line-voltage relay power input, output and pass-through with support for 14-8 AWG wire - Low-voltage 0-10V dimming output per zone with support for 22-16 AWG wire - Separate normal power sense feed input for UL924 emergency lighting bypass - UL924 emergency lighting control contact closure input with support for 22-16 AWG wire - Demand Response contact input with support for 22-16 AWG wire • Demand Response input supports Normally Open (NO) operation • UL924 contact closure input supports normally open (NO) or normally closed (NC) operation • Onboard status indicators for controller power, DMX signal, Demand Response input, and UL924 emergency lighting control • Slide switch configuration for: - UL924 operation (NO/NC) - UL924 inclusion per circuit (on/off) • UL and cUL LISTED - Conforms to UL508, UL2043, UL916 and UL924
DMX INPUT PORT • Optically-isolated input from the Mini Panel electronics • Withstands fault voltages of up to 250VAC • Integrated DMX/RDM termination
CONFIGURATION • Remote configuration available via RDM devices such as: - ETC control console with RDM functionality - ETC DMX/RDM gateway networked to a device running ETC Net3 Concert software • Manual configuration of the starting DMX address, UL924 bypass, and Demand Response on the controller
THERMAL • Ambient room temperature: 0 to 50°C • Ambient humidity: 5 to 95% non-condensing
