ETC UBPO Unison DRd Ride-Thru Power Backup Kit
Engineered for easy maintenance, the BatteryPack Option installs on the bottom of Unison DRd or ERn enclosures and keeps the processor energized in the event of power loss or interruption to the enclosure. One of two PowerSupport options, the BatteryPack Option is designed for applications where the Architectural Control Processor must remain online during power loss providing power for up to 90 minutes.
APPLICATIONS
• Houses of worship
• Hotels
• Convention centers
• Theaters
• Meeting rooms
• Schools
• Museums
• Restaurants
• Themed entertainment
FEATURES
• Designed for use in Unison DRd and ERn Enclosures
• Compatible with Paradigm Architectural Control Processors
• Long term power back-up of control electronics for at least 90 minutes (40 minutes when used in ERn4 with two Paradigm Architectural Control Processors)
• Automatically engages when power is lost
• Recharges during normal power operation
GENERAL
• UL and cUL LISTED
• CE marked
SPECS
GENERAL
• Provides power for a single Architectural Control Processor for 90 minutes
• Provides power for two architectural control processors (ERn4 only) for 40 minutes.
• UL and cUL LISTED
• CE Marked
FUNCTIONAL
• Designed for use in Unison DRd and ERn Enclosures
• Compatible with the Paradigm Architectural Control Processor
• Seamless transfer from charge to power output without user intervention
• Recharges during normal power operation
• Prevents the Architectural Control Processor from rebooting when power returns
- Allows for immediate control of the full system as soon as normal power is present
MECHANICAL
• 18-gauge formed steel construction
• Fine-texture, scratch resistant, epoxy paint
• Field installed without tools
• Visible indicator lights clearly identify when the battery is providing power and if maintenance is required
• Installs using fctory provided wire harness with no additional wiring required
ELECTRICAL
• Seamless transfer to battery power upon loss of normal power
• Provides 24vDC power for Control processor during power loss
• Provides backup power for 90 minutes during normal power loss
• Automatically recharges from power feed during normal power conditions
• 2 Hour recharge time from full discharge
• Factory provided connectors for wiring terminations
• UL and cUL LISTED, CE Marked
THERMAL
• Ambient room temperature: 0-40°C / 32-104°F
• Ambient humidity: 10-90% non-condensing
