Product Description

ETC SELD22 Desire D22 Par Lighting Fixture, Track Mount

Small size, big attitude

Don't let the size of the Selador Desire D22™ LED luminaire fool you. It may be small, but it packs a punch. With 22 Luxeon® Rebel LED emitters, the budget-friendly D22 offers efficient ETC Desire®-quality lighting in a small eight-inch footprint weighing less than seven pounds.

The Studio Daylight array produces cool white light that looks just like natural sunlight. This array contains 5600K LEDs for high-intensity, non-variable cool-white output

The Studio Tungsten array creates warm white light that mimics the performance of tungsten fixtures. This array contains 3000K LEDs for high-intensity, non-variable warm-white output. They look great in person and on camera.

The Studio HD array combines warm white and cool white LEDs for variable-color-temperature mixing. Added to the mix are carefully chosen colors from the Selador x7 Color System to allow for tint adjustment (+/- green) while also filling in the white LED spectral gaps. This provides a high quality and tunable white-light source.

GENERAL INFORMATION

ETC’s Selador Desire D22 luminaire puts the x7 Color System™ into a compact, round washlight. Highly efficient primary lenses and careful color choices make the D22 fixture ideal for stage, studio, architecture and anywhere vibrant color and high intensity are requirements. The Selador® x7 Color System produces the widest range of spectrally-balanced saturated and tinted color choices available, while the static-white options provide an impressive punch. D22’s rugged die-cast enclosure, noiseless fan-free operation, multiple lens options, convenient size and advanced user interface make it an ideal addition to the Desire family of LED luminaires.

D22 LED ARRAY D22 fixtures are available with any one of the following arrays (not interchangeable) to best suit the intended application.

• D22 Lustr+™: Optimized array with six colors plus, highintensity white LEDs to create an ideal wash fixture for fullrange color
• D22 Studio Daylight: Contains twenty-two 5600K LEDs for high-intensity, non-variable cool-white output
• D22 Studio Tungsten: Contains twenty-two 3000K LEDs for high-intensity, non-variable warm-white output
• D22 Studio HD: Combines warm white and cool white LEDs for variable-color-temperature mixing. Added to this are carefully chosen colors from the Selador x7 Color System to fill in the white LED spectral gaps, providing the richest variable-white light possible in an LED fixture.

D22 MOUNTING CONFIGURATIONS

D22 fixtures are available in three different mounting options to fit any installation:

• D22 Portable: Standard yoke-mount hardware; power lead with Edison connector and DMX in/thru connectors
• D22 Install Canopy: Standard yoke-mount and canopy hardware; power lead with bare ends; and a permanent, single DMX in/thru cable
• D22 Track-Yoke: Track adapter and a single, permanent cable for both power and DMX in

SPECIFICATIONS

GENERAL

• 22-LED color-mixing wash fixture (Lustr+™)
• 22-LED variable white-light fixture (Studio HD)
• 22-LED static cool- or warm-white wash fixture (Studio Tungsten and Studio Daylight)
• ETL listed general purpose lighting
• IP20-rated for indoor use
• DMX in/thru for easy setup (no DMX thru on D22 Track)
• User-friendly control interface with multiple modes and fixture settings
• Permanent power input cable connected

PHYSICAL

• Rugged die-cast all-metal housing
• Easy access slots for secondary lenses and 5.5” accessories
• Available in black (standard), white, silver (optional) or custom colors (contact factory)
• Hanging yoke standard • DMX512 in/thru via five-pin XLR connectors (D22 Portable only)
• IP20 for Portable and Canopy versions
• IP40 for Track version

ELECTRICAL

• 100VAC to 240VAC 50/60Hz universal power input
• 20 fixtures total per circuit when used with R20 Relay Module or Unison Echo Relay Panel. Consult breaker trip curves when used with other equipment
• Requires power from a non-dim source
• Inrush - 120V: 17A - 240V: 25A

LED

• 50,000-hour LED life (50,000 hours at 70% intensity)
• 22 Luxeon® Rebel LED emitters

COLOR (LUSTR+ AND STUDIO HD ONLY)

• Exclusive x7 Color System™ seven-color LED array (Lustr+)
• Unique mix of x7 colors and warm and cool LEDs (Studio HD)
• Beautifully illuminates skin tones and other objects for natural appearance and high color rendering
• Broad-spectrum color interacts seamlessly with conventional sources
• Exclusive, optional red-shift option emulates tungsten dimming performance

OPTICAL

• Primary field angle of 21°
• Secondary lenses available for multiple beam spread options
• Refer to accessories charts for lenses available

CONTROL

• Multiple control options, including RGB, strobe, and consolefree Master/Slave mode
• See DMX Control Table for additional information
• 15-bit virtual dimming engine provides smooth, high-quality theatrical fades, and minimizes color shift during dimming
• RDM functionality for address and setting changes

THERMAL

• Ambient operating temperature of 32°F to 104°F (0°C to 40°C)
• Active electronic thermal management for droop-free operation
• Noiseless, fan-free convection cooling for acoustically sensitive installations
• Fixture is designed for continuous operation up to 104°F (40°C) ambient temperature and requires free flow of air around fixture housing

ADDITIONAL ORDERING INFORMATION

Connector Options

Use information below to order input with factory-fitted connectors

MODEL AND DESCRIPTION

• N/A - Portable with Edison connector
• -I - Install Canopy Mounting
• -T - Track Mounting

Fixture Accessories

MODEL DESCRIPTION (order separately)

• SELD22BD Barn door (Use only as a flexible top hat to diminish aperture glare. Not for beam shaping.)
• SELD22CF 5.5” Color Frame (use for round and oblong lenses)
• SELD22ECL Egg Crate Louver
• SELD22HS Half-Shield
• SELD22FSY Yoke with floor stand attachment
• 400CC C-Clamp (does not ship with fixture)
• 400SC Safety Cable (32”)

Note: All model numbers above are for black accessories. Add -1 for white or -5 for silver. Custom colors are available upon request.

Secondary Lens Options (order separately)

MODEL DESCRIPTION: The following lenses are cut for D22 fixtures and create round, linear or oblong field patterns as described below. These lenses are not sized for use in Selador® Classic (Vivid-R™, Lustr®, Paletta™, etc.) fixtures.

Narrow Linear Field Note: This is the same material as SeladorClassic lenses

• SELLVN-D22 - Very Narrow lens (narrow linear field) Linear lenses may be combined to create desired field size, i.e. 40° X 60°
• SELLN-D22 - Narrow lens (narrow linear field)
• SELLM-D22 - Medium lens (narrow linear field)
• SELLW-D22 - Wide lens (narrow linear field)
• SELLXW-D22 - Extra Wide lens (narrow linear field) Round Field
• SELRVN-D22 - Very Narrow lens (round field)
• SELRN-D22 - Narrow lens (round field)
• SELRM-D22 - Medium lens (round field)
• SELRW-D22 - Wide lens (round field)
• SELRXW-D22 - Extra Wide lens (round field) Oblong Field
• SELON-D22 - Narrow lens (oblong field)
• SELOM-D22 - Medium lens (oblong field)
• SELOW-D22 - Wide lens (oblong field)

NOTES ABOUT LED LUMINAIRES

All LED sources experience light-output reduction and some color shift over time. LED output will vary with thermal conditions, which can be affected by ambient temperatures and orientation. See the D40 Ambient Temperature and Power Budgeting Guide for more details. Based on the LED manufacturer’s B50 L70 specification, a Selador luminaire will achieve ~70% of its initial output after 50,000 hours of typical usage. In individual situations, LEDs will be used for different durations and at different levels. This can eventually lead to minor alterations in color performance, necessitating slight adjustment to presets, cues or programs.

CRI AND CQS RATINGS

Desire fixtures were evaluated for CRI and CQS performance using measured output spectrum and optimized mix solutions for the best spectral match to black body sources at 3200K and 5600K.

The D22 luminaire provides excellent color rendering to the eye, particularly at higher color-temperature settings such as 5600K. A Duv rating of 0.000 indicates that the color mix used is exactly on the black body line, with no green or magenta tint.

LENS INFORMATION

Desire diffusion angle measurements

*Values in black refer to old lens descriptions.*

CONTROL OPTIONS

User settings on D22 fixtures allow multiple operational modes and settings for either console operation via DMX protocol or stand-alone operation. The expanded LCD display provides easy navigation to all possible settings and options. Some of them are:

• Multiple DMX choices, ranging from a simple RGB profile – which effectively controls all seven LED colors via three channels – to nine-channel ‘direct’ color and intensity control
• Multiple dimming curve options
• Preset colors and sequences for stand-alone (no console required) operation
• White-point selection: White-light and color behavior based on a specific-color-temperature white light, i.e. 3200K, 5600K, etc.
• Loss of data behavior options: Instant off, hold last look for two minutes, etc.
• Output modes: Three output options that offer the user a choice between maximum output and maximum consistency

See the user manual for a complete explanation of all of the control settings and options for the D22.

Quick Setups

To assist in managing the numerous control and fixture behavior choices, five combinations of operational settings are available to quickly get started. These settings are specifically created for different applications and are easily accessible at the fixture display. Each setting can then be modified as required to take advantage of all of the possible control features
