ETC ROS-KM-UW Resonate Occupancy/Vacancy Sensor for Wall-Mounting - Corner
Overview
The ROS wall-mounted sensor that uses passive infrared (PIR) technology to detect occupancy. It uses wireless technology to communicate with Echoflex controllers to efficiently manage lighting and increase energy savings. The ROS sensor is not only easy to install and maintain, but also an affordable, reliable device for retrofit or new construction projects.
The sensor harvests solar energy from both natural and artificial light sources. Its efficient energy management system ensures continuous operation long after the lights are off, up to eight days in complete darkness. The ROS is suitable for vacancy applications where energy codes require lights to be manually turned ON and automatically shut OFF or dimmed when the space is vacant. Precision circuitry also allows it to provide immediate response to new occupancy states, making it an ideal solution for partial-ON/auto-ON applications.
The ROS incorporates test features that provide installers with the ability to ensure, sufficient energy harvesting, and occupancy detection without extra tools or software. Sensitivity settings for PIR can be adjusted to eliminate false tripping and ensure the right level of detection.
The ROS occupancy sensor is available in models for wide angle, corner mount, and hallway or high-bay end-of-aisle applications.
Features
- Solar powered wireless occupancy sensor
- Reliable radio reception range of 24 m (80 ft) - commercial office spaces (typical), up to 100 m (330 ft) line of sight
- Operates with no light on a full charge for over 200 hours
- Operates in low light conditions, under 25 lux (2.5 fc)
- Adjustable PIR sensitivity to fine-tune detection level
- Walk test mode ensures motion range coverage
- Hallway, corner mount and wide angle mounting applications
- Removable back plate for easy mounting
- Optional battery start assist
- Quick start-up operation, under 3 minutes @ 200 lux (20 fc)
