Product Description
ETC PSP-100 PowerSafe Pro 100A
PowerSafe Company Switches come in two models:
• PowerSafe Pro : 100A, 200A, 400A
• PowerSafe Compact : 100A, 200A
PowerSafe Pro sets a new standard in safety and size. It offers important new features: locking connection covers, shunt-tripprotected doors that can lock connection covers in place while output power is present, and lockout/tagout brackets.
A fault-current-limiting option provides additional safety in the event of a short circuit, by limiting the energy available at the output of the switch. This option reduces the available fault current via ultra-fast current-limiting fuses, allowing safe connection of equipment with lower SCCR (Short Circuit Current Rating) and reducing arc-flash hazard. In addition to safety features, both models provide 65kA SCCR ratings with 100% rated breaker for lighting, sound, scenery, and stage equipment.
FEATURES
PowerSafe Pro
• PowerSafe compartment: Protects against access to output connections while the cabinet is energized
• Double Neutral: Supports 200% rated neutral
• LED Worklight Option: Illuminates interior and output lugs
All Models
• Shunt trip safety interlock
• SCCR: Provides 65,000A Short Circuit Current Rating
• Iso Ground: Allows field configuration of isolation between enclosure ground and equipment ground
• Output Connections: Accommodates single-pole cam-style connectors and up to 4/0 class K cables using 500kcmil screw terminal
• Power Indicators: LEDs light up to show that power is on/available between each phase and neutral
• Lockout/Tagout: Accepts third-party locks on built-in bracket for support of NFPA 70E safety lockout/tagout procedures
APPLICATIONS
Entertainment venues requiring temporary power, such as:
- Theaters
- Convention centers
- Auditoriums
- Exhibition halls
- Studios
- Performing arts centers
- Arenas Casinos Stadiums
SPECS
GENERAL
• UL and cUL Listed
• Meets/exceeds all applicable NEC standards
• Satisfies safety requirements for lockout/tagout
• Short Circuit Current Rating (SCCR): 65,000A RMS symmetrical
MECHANICAL
• Wall-mount unit with integral keyhole fixing points
• 16-gauge welded steel cabinet, rated NEMA 1
• Locking swing hinged door with clamp latch
• ETC Sensor styling with fine-textured, scratch-resistant epoxy paint
• Secondary door for access to bare-end tie-ins
• Conduit entry via top or side (see manual)
• Solid, top and side panel free of conduit knockouts to allow for greater flexibility in contractor conduit entry
• Integral breaker lockout bracket supports standard lockout/tagout procedures to prevent any persons from turning the breaker “on” while the lock is in place
ELECTRICAL
• Power input:120/208V – Three-phase, four-wire plus ground
• Copper and aluminum feeders are allowed
• 65,000 AIC 100% rated 100A, 200A, or 400A breaker
• 65,000A SCCR symmetrical rated system
• Optional fault-current-limiting fuses reduce available let-thru current to connected portable equipment
• Reverse neutral and ground cam-style connector configuration
• Current transformers can optionally be installed in the field for connection to external third-party power meters
• Safety interlock disconnects output power when cabinet door is opened
PROTECTION FROM LIVE CONNECTIONS
PowerSafe Pro
• Door-covered “Fingered” cable entry for safe access through the front of the panel
• “Fingered” cable entry made of foam rubber surface for prevention of wear and tear on cabling
PowerSafe Compact
• Swing-hinged brackets lock covers in place until the front door is opened, preventing connector insertion under power
