Product Description
ETC MSS-2F-U 2 Button Multi-Scene Station - Fade Up/Down
Overview
The Multi-Scene Station communicates wirelessly with Echoflex lighting controllers. It delivers control of blended color temperature and light intensity to spaces where innovative architectural lighting is desired. The MSS is available in four different colors and six different button formats that modulate light intensity, color temperature, and recall preset scenes on controllers. Using preset values on the Echoflex controllers it is linked to, the MSS can provide designed lighting and scene sequences for specific spaces or zones easily.
The low-profile haptic buttons and clean faceplate with discreet LED indicators give the MSS a sleek contemporary appearance. The MSS is powered by a replaceable coin cell battery and has an expected lifetime of 100,000 actuations over 10 years. When the battery runs low, a red LED blinks when any button is pressed.
The MSS is designed to fit in a standard wall outlet or mud ring (back support plate provided) or can be installed flush mounted with screws. For installations over line voltage boxes, a separate barrier plate kit is available. See the Accessories section for UL approved barrier kits.
Features
- Wireless low profile scene station with screw-less face plate
- LED indicators and haptic buttons
- Available in multi-button formats and choice of colors: white, black, gray, or cream
- Reliable radio reception range of 24 m (80 ft) - commercial office spaces (typical), up to 100 m (330 ft) line-of-sight
- Powered by replaceable coin cell battery (CR2032), 100,000 actuations or ten-year battery life
- Installation options: Flush mount with screws, on a mud ring with back support plate, or over a line voltage electrical box with UL approved barrier, sold separately
