Product Description
ETC MSCX50-VCC Mk3 Mosaic Show Controller X 50 Mk3 with VCC (25,600 Channels)
Overview
Mosaic Show Controllers (MSCs) are the permanent part of your installation supporting DMX512 and DMX-Over-Ethernet protocols to control color-mixing fixtures, conventional dimmable fixtures and automated lights. The MSC X Mk3 is available in capacities up to 51,200 outputs from a single controller. The MSC X Mk3 has an extensive range of external and onboard triggering interfaces, including audio input for linear timecode and RS232 serial, as well as a built-in timeclock to trigger astronomical and lunar events. Additional triggering interfaces are supported by networking with Mosaic Remote Devices. The MSC X Mk3 empowers you to send the data to your network using multiple DMXover-Ethernet protocols simultaneously.
Features
- Playback for a wide range of fixture types and devices
- Pixel mapping for video effects
- DMX-over-Ethernet data output
- Built‑in triggering interface with conditional logic and timeclock based controls
- VideoConnect: Digital-video input for live-video mapping via optional capture card
- RealEngine: ensures an accurate representation of your show whether in software simulation or when played live to connected controllers
- DesignerAccess: internal web server with active pages providing status, configuration information, remote monitoring, and remote show uploads
- Programmed and configured using Mosaic Designer 2 software (version 2.11 and later)
