Product Description
ETC MRIO-D4 Unison Mosaic Remote DALI Module 4 Loops
Overview
The Mosaic Remote DALI 4-Port module (MRIO-D4) is a remote input/output device that expands the advanced control capabilities of Mosaic to control Digital Addressable Lighting Interface (DALI) drivers and ballasts. The MRIO-D4 supports control for four DALI subnets, which can be configured as outputs for control and configured to receive DALI commands that trigger the Mosaic system. Mosaic affords you the most convenient and scalable way to control DALI fixtures and ballasts. Each DALI port supports up to 64 devices and each Mosaic system supports up to 500 DALI interfaces. The MRIO-D4 is a DIN rail mounted PoE device that can be deployed in the system anywhere it is needed and connects to a compatible Mosaic Controller over an Ethernet network.
Features
- Controls four DALI subnets across four DALI interfaces (up to 256 DALI devices total per module)
- Supports DALI discovery and configuration commands
- Multiple MRIO-D4 devices can be combined on the same network to build the ideal scalable network of DALI devices
- Supports emergency DALI devices
- Power over Ethernet (PoE) powered for optimal distributive control over and Ethernet network
