Product Description
ETC MRIO-08 Mosaic Remote I/O - 0 In/8 Out
The Mosaic Remote Input/Output Modules (MRIOs) expand the advanced show-control capabilities of the system in interactive installations, allowing lighting and AV to respond instantly to the environment or viewer. As accessories to the Mosaic Show Controllers(MSCs), Mosaic Show Controller X (MSCX) and Mosaic Audio/Video Controller (MAVC), Remote I/O devices offer an integrated, bi-directional serial port (RS232/RS485) for interfacing to third-party equipment or systems and employ familiar, simple and reliable Ethernet-wiring topology with IEEE 802.3af Powerover-Ethernet (PoE). Specialized RIO devices also offer integration capabilities for Audio, Contact Inputs, Contact Outputs, and more. Up to 100 RIO I/O modules can coexist on a network as part of a distributed system.
APPLICATIONS
• Integration with 3rd party products and systems
FEATURES
• MRIO 80
- The RIO 8/0 features eight configurable Tri-Mode inputs that accept almost any input from the necessary equipment: digital-active high, digital-active low, or contact closure.
• MRIO 44
- When you need both input triggers and control over other devices in the same location, choose the RIO 4/4. Featuring both relay outputs and configurable Tri-Mode inputs, the RIO 4/4 allows you to integrate with almost any third-party device.
• MRIO 08
- When you need to issue commands to third-party devices, the RIO 0/8 gets the job done with eight fully isolated relay outputs.
• RS232/485 serial output, or up to 96 channels of DMX output
GENERAL
• ETL/cETL Listed
• CE Compliant
SPECS
GENERAL
• MRIO 80
- The RIO 8/0 features eight configurable Tri-Mode inputs that accept almost any input from the necessary equipment: digital-active high, digital-active low, or contact closure.
• MRIO 44
- When you need both input triggers and control over other devices in the same location, choose the RIO 4/4. Featuring both relay outputs and configurable Tri-Mode inputs, the RIO 4/4 allows you to integrate with almost any third-party device.
• MRIO 08
- When you need to issue commands to third-party devices, the MRIO 0/8 gets the job done with eight fully isolated relay outputs. Programmed and configured using Unison Mosaic Designer Software
• RS232/485 serial output, or up to 96 channels of DMX output
FUNCTIONAL
• Support for up to 100 of each MRIO I/O module in any Mosaic Control System
• Serial connectivity using RS232 or RS485 per module, or optional DMX output for up to 96 channels
• Remote Firmware Upload
MECHANICAL
• 4 unit wide DIN Enclosure
• Mounting complies with DIN43880 and EN60715 (35/7.5 rail)
• Rotary switch for selecting network address
• All connections use standard plugable connectors
ELECTRICAL
• 10/100Base-TX Ethernet using RJ45 connection
• PoE power input (IEEE 802.3af) (Required)
• 10-bit ADC analog inputs (MRIO80 and MRIO44)
• Isolated tri-mode digital inputs (MRIO80 and MRIO44)
- Support active high, active low, or contact closure
• Isolated relay outputs (MRIO44 and MRIO08)
- 1KV isolation - Support up to 250mA at 48VDC
• RS232 or RS485 Serial using 3-pin Camden header
• ETL and cETL Listed, CE compliant
THERMAL
• Ambient temperature: 0-50°C / 32-122°F
