Product Description
ETC M108-4-US Mosaic 8-Button Station
Mosaic Button Stations interface with any Mosaic control system using a Power-over-Ethernet network. With support for up to 100 stations, button stations can be placed remotely to trigger system timelines and functions. Simple addressing using a rotary switch is provided on the rear of the station, and Mosaic Designer software is used to assign button actions and LED indicator responses. Mosaic Button Stations are available with faceplates for North American and European installations.
APPLICATIONS
• Museums
• Fountains
• Installations that require manual triggering
FEATURES
• Embossed magnetic overlay with a low-profile bezel
• No visible means of attachment
• Color options to compliment any interior design
• Eight programmable buttons
• White LED button indicators with intensity control
• Power-over-Ethernet (PoE) Networking to Mosaic controllers
• US and European faceplates available
• Built in IR receiver with support for 3rd party remote
• Programmed and configured using Mosaic Designer Software
REGULATORY AND COMPLIANCE
• cETLus Listed
- Conforms to UL-60950-1
- Certified to CAN/CSA-C22.2 No. 60950-1
• CE Compliant
• California Title 20/24 compliant
SPECS
FUNCTIONAL
• Programmable buttons for triggering mosaic timelines or functions on a connected Show Controller
• Independently configured LED backlight per button
• Support for up to 200 button stations in any Mosaic system
• Learning IR receiver supports eight IR inputs from any 3rd party remote control
• Remote firmware upload
• Five year warranty
MECHANICAL
• Eight tactile buttons with LED indicators
• Standard, 1-gang US and European faceplate options
• Available in cream, black, white, or polished bezel with black overlay finishes
• No visible means of attachment
• Integrated IR receiver
• Rotary switch for selecting network address
• Uses standard 1-gang flush mount electrical box, or equivalent. (provided by others)
- Surface mount back boxes are available from ETC
ELECTRICAL
• RJ45 connection for 10/100Base-TX Ethernet with link and data LED with Static and DHCP addressing support
• PoE powered (IEEE 802.3af, Class 1) 1.5W typical draw
THERMAL
• Ambient temperature: 0-50°C / 32-122°F
• 10-50% relative humidity, non-condensing
