  • ETC IRT SRP-280

    • ETC IRT SRP-280 TRANS Occupany Sensor Remote Programmer

    $101.60
    SKU:
    IRT SRP-280
    UPC:
    PSM1170
    Condition:
    New
    Availability:
    Typically ships in 3-5 business days
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    ETC IRT SRP-280 TRANS Occupancy Sensor Remote Programmer

    OVERVIEW

    The SRP-280 is a universal two-way remote programming device designed to provide easy configuration of the remote programmable TRANS sensors from IR-TEC. This handheld programmer not only allows you to configure the sensors, but also download the current settings of the installed sensor from the floor via intuitive keypad operation. The remote does away the need for ladders, scissors lifts, bucket trucks or any other tools. A bi-directional infrared optical communicator enables not only uploading the new setting parameters to the sensor, but also downloading the current settings and dim level output from the sensor. Up to 4 EZ-SET and an additional default profile can be recalled, modified and saved for quick setting of multiple sensors with identical parameters. In addition to sensor programming, the SRP-280 can also be used as a typical remote to control local lighting manually. This device not only makes ladder-free sensor and control parameters setting possible, but also provides an easy way to verify conformity with design intent.

    FEATURES

    • Exceptionally long range 2-way communication
    • Intuitive operation makes commissioning faster
    • Upload and download status acknowledgement
    • Easy to duplicate one sensor setting to another
    • Set SmartDIM level to deliver optimum lighting
    • Capable of reading the current dim output level
    • Set ambient light level for daylight harvesting
    • Set high/low dim level output for bi-level control
    • EZ-SET profiles enable setting multiple sensors Various time settings for burn-in and operation
    • Rubber jacket provides superb drop protection

    OPERATIONS

    The SRP-280 TRANS Sensor Remote Programmer is powered by two AAA batteries. Intuitive keypad operation with instruction on the LCD makes sensor setting and programming an easy job. In addition, it can be used like a typical remote control to turn on and off the local lighting manually.

    SETTING

    The SRP-280 can program applicable settings of any remote programmable TRANS sensor, including control mode, ambient light level, OFF delay, Time Off delay, high/low dim level, SmartDIM level, ramp-up/fade-down speed, sensitivity, burn-in time, test mode, save and recall EZ-SET profiles, factory default reset…etc.

    UPLOAD

    The SRP-280 can easily upload control parameters to a single or multiple sensors through easy, intuitive keypad operation. To upload the sensor with new settings, just select the available parameters on the remote, go to the UPLOAD page, aim the remote toward the target sensor, press the “ENTER” key and hold for uploading completed. Once the program is completely uploaded to the sensor, the LCD will display message, and the connected light will flash to acknowledge the upload completion.

    DOWNLOAD

    To download the current settings, just enter the DOWNLOAD page, aim the SRP-280 at the sensor and hold to receive the data from sensor after pressing the “ENTER” key. The LCD will display message to acknowledge the download status. All current settings will be displayed on the LCD after the download is completed.



    Other Details

    Warranty Coverage. ETCWILLONLY BE OBLIGATEDTO HONORTHE WARRANTY SET OUT BELOWUPON RECEIPTOF FULLPAYMENTOF THEORDER. Electronic Theatre Controls, Inc. (“ETC”) warrants to the original owner or retail customer (“Customer”) that during the warranty period defined below, ETC will repair or replace its Products that are defective in materials or workmanship which cause the Product to fail to operate in accordance with ETC’s published specifications for the Product in effect as of the date of shipment, subject to the terms of this limited warranty. The warranty period of box Products shall begin on the date of shipment (“Warranty Start Date”), except the Warranty Start Date shall begin on the date of energization for Orders which include energization performed by ETC or an authorized serviceprovider acting on ETC’s behalf. If no energization date is recorded, however, the Warranty Start Date shall begin on the date of shipment. The controlling warranty, terms and conditions, and product warranty periods is available at the time of order acknowledgment, either by hard copy or by the PDF document found via the internet link listed on the order acknowledgment as of the date of the order acknowledgment. If ETC shall fail to repair or replace defective Products within a reasonable time after they are returned to ETC, or if ETC shall wrongfully fail to make delivery or shall wrongfully repudiate this contract, then Customer shall be entitled to recover from ETC such part of the purchase price as has been paid by Customer to ETC. The remedy stated in the preceding sentence shall be Customer’s exclusive remedy for any breach, non-delivery, or repudiation by ETC or for any other liability of ETC to Customer. This exclusive remedy shall not be deemed to have failed its essential purpose so long as ETC is willing and able to repair or replace defective Products in the prescribed manner. Warranty Exclusions. This Warranty does not impose any liability or duty upon ETC for: (i) any Product or part of a Product damaged by or subject to accident, negligence, alteration, abuse or misuseby Customer, or any accessories or parts not supplied by ETC;(ii) any damagecaused by the unauthorized adjustment, repair or service of the Products by anyone other than ETC or its authorized repair agents; (iii) any damage, to any Product, or part of a Product caused by or due to an act of God, any catastrophe resulting from earthquake, fire, flood, explosion, inability to obtain materials or utilities, or any other cause beyond the reasonable control of ETC. This warranty also does not cover “consumable” parts such as fuses, lamps, color media or components which may be warranted directly to the Customer by the original manufacturer. This Warranty does not extend to items not manufactured by ETC. Freight terms on warranty repairs are FOB ETC factory or designated repair facility. Collect shipments or freight allowances will not be accepted.
