Product Description
ETC Ion Xe 2K lighting console with 2048 outputs
Small console. Mighty control.
The Ion® Xe is the compact workhorse of the Eos® family. Featuring the same backlit keyboard layout and full-feature software as its bigger siblings, this little desk brings professional programming power to any venue. Ion Xe can integrate into a system with all other Eos family products (except Element), and you can transition between desks with ease.
The Ion Xe is available in either 2,048 or 12,288 outputs, and provides support for up to two external monitors. The master playback faders can be supplemented with virtual faders or a variety of other options.
Expanded fader control
Looking for more hands-on control in the same package? The Ion Xe 20 features an onboard fader bank that includes 20 pageable faders and a built-in display.
As with any Eos family desk, you can always further expand your fader count of Ion Xe or Xe 20 by connecting one or more Eos Fader Wings or Eos Motorized Fader Wings.
Ion Xe has your back(up)
Need a backup or a rack-mountable primary controller? Enhance your system with an Ion Xe Remote Processor Unit to create a convenient control hub backstage or on the tech table or to provide security for your long-running show.
SPECIFICATIONS
SYSTEM CAPACITY
- 2,048 outputs
- 32,768 Channels (mapped to any number between 1 and 99,999
- 10,000 Cues
- 999 Cue Lists
- 999 Submasters
- 4 x 1000 palettes (Intensity, Focus, Color, Beam)
- 1000 presets (all palette)
- 1000 Groups
- 1000 Effects (relative, absolute or step)
- 99,999 Macros
- 1000 Snapshots
- 1000 Curves
- 1000 Color paths
- Supports a maximum of two external display port monitors at 1280x1024 minimum resolution or multi-touch screen control
- Solid-state hard drive
- Five USB ports for flash drives, pointing devices, keyboards
INTERFACES
- Four DMX-512 / RDM ports
- Ethernet (ETCNet2™, Net3™,Artnet and Avab UDP output protocols)
- Contact Closure triggers via D-Sub connector
- Two Display port connectors support two external displays with optional touch- or multi-touch screen control
- MIDI Timecode, Notes, Show Control through Gateway
- SMPTE Timecode through Gateway
- Additional contact closure (12 analog inputs, 12 SpDT contact outputs, RS-232) through Gateway
- OSC Transmit and Receive
- UDP Transmit and Receive
Eos Family Offline Editor software for Mac and PC platforms is called ETCnomad and is available for download from www.etcconnect.com
Ion Xe requires Windows 7 compatible external monitors, 1280x1024 minimum resolution, standard, touch or multi-touch
SHIPS WITH:
• Dust cover
• One Littlite
• Mouse and mousepad
• External alphanumeric keyboard
• Two active display-port to DVI adapters
• One locking IEC power cord
