Product Description
ETC FDR12FD F-Drive R12 Rack Mount Driver Enclosure and Control Card
Overview
The F-Drive R12 LED driver solution from ETC provides a modular, centralized approach for controlling LED luminaires. By maintaining remote, easy access to driver cards and power supplies, LED based systems can be easily installed and serviced, while ensuring critical components are readily accessible to support staff.
Features
- 48 VDC Input (via separate power supply)
- Hot-swappable output cards
- RJ45 output connectors for use with CC, FTW, and Chroma output cards
- Modular output connectors for higher gauge/existing wire (Max 14 AWG / 2.5 mm²)
- DMX512/RDM control input
- Wet/Dry contact panic input for remote triggering of output channels
