Product Description
ETC FD-BBOX-4T B-Box Four Output Breakout Box - Terminal
Overview
The F-Drive B-Box is an accessory that greatly expands the connection capabilities of the F-Drive LED driver system. With the B-Box, system designers can convert a Cat6 cable run with an RJ45 into four different single-channel outputs, for Molex, two-pin terminal, or even single-channel RJ45 cable runs. The B-Box is compatible with all CC and FTW output models in the F-Drive R12 and W1 product line. Installations using third-party luminaires will benefit from the increased compatability options B-Box adds to the centralized F-Drive system.
Features
- Receives RJ45 via Cat6 cable from an F-Drive CC or FTW output card
- Provides four outputs, one for each channel, via Molex, twopin terminal, or RJ45 connector depending on model
- RJ45 model supports ArcSystem Navis White or Fade to Warm
- Molex model supports ArcSystem Pro One-Cell, Pro One-Cell Small, and Pro One-Cell Micro White or Fade to Warm luminaires
- Terminal model supports constant current loads requiring 200–700 mA
