Product Description
ETC Nomad Puck (Base Unit) Lighting Controller Kit with 1,024 Outputs and RVI
**The Gadget and/or network equipment must be purchased separately from the ETCnomad Lighting Control kit.
The ETCnomad Puck lighting controller is a full-featured minicomputer with an embedded ETCnomad lighting control key capable of running Eos and Element applications. It provides lighting control with conventional and moving lights, media servers and LED luminaires. The ETCnomad Puck lighting controller can be used in primary, backup, client and offline environments. Optional fader wings, programming wings, X-keys and compatibility with USB–MIDI panels allow extended and customizable control.
FEATURES • The base unit is 1,024 outputs. This can be upgraded to 6,144 outputs • The ETCnomad Puck lighting controller makes an ideal tech table RVI • Operates in stand-alone, primary, backup and client environments • When connected as a client, output capacity is determined by the system to which it is connected • Net3/ACN/sACN and Artnet Ethernet lighting protocols • DMX/RDM via ETC Gadget or Gadget 2 • DMX/RDM via Net3 DMX/RDM Gateways • One HDMI and one Mini Display Port (Mini Display Port to HDMI converter included) • Four USB ports • OSC Transmit/Receive • UDP Transmit/Receive See Eos and Element datasheets and operation manuals for ETCnomad lighting control features
ACCESSORIES • Eos Programming Wing • Eos Motorized Fader Wings (10 or 20) • Eos Standard Fader Wings (20 or 40) • ETCpad • aRFR/iRFR remote controls • Alphanumeric keyboard • USB mouse
ORDERING INFORMATION
MODEL DESCRIPTION
- ETCnomad Puck Base ETCnomad Puck Lighting Controller Kit, 1,024 outputs and RVI
- ETCnomad Puck Unlocked ETCnomad Puck Lighting Controller Kit, 6,144 outputs
- ETCnomad Up After-sale output upgrade
IMPORTANT ETCNOMAD LIGHTING CONTROLLER ORDERING INFORMATION Local DMX output may be distributed using an Gadget 2 USB to DMX/RDM converter. Up to four DMX outputs are supported. Additional or all outputs may be distributed via Ethernet protocols directly (Net3/ACN/sACN, or ArtNet) or by compatible Ethernetdistribution hardware, such as Net3 DMX/RDM Gateways. The Gadget and network equipment must be purchased separately from the ETCnomad Puck lighting control kit.
Note: The ETCnomad Puck lighting controller does not support ETCNet2/EDMX protocol.
Note: Eos software 2.8.X or below unlocks the base dongle at 512 outputs. Eos software 2.9 or higher unlocks the base dongle to 1,024 outputs.
Note: ETCnomad Puck is also compatible with Cobalt.
Important Note: The original Puck (with three USB ports) can be upgraded to 2,048 outputs only. Use ETCnomad 1.5K Up to order an after-sale upgrade for this unit.
Ships with: • US power cord • Mini Display Port to HDMI adapter • VESA mounting bracket
ETCnomad Puck Accessories
MODEL DESCRIPTION
- Eos PGW Eos Programming Wing
- Eos MFW 20 Eos Motorized Fader Wing 20
- Eos MFW 10 Eos Motorized Fader Wing 10
- Eos FW 40 Eos Standard Fader Wing 40
- Eos FW 20 Eos Standard Fader Wing 20
- ETCpad ETC Portable Access Device
- GADGET 2 ETC Gadget 2 USB to DMX/RDM Converter
ETCnomad lighting control software is available for download from etcconnect.com/Products/Consoles/Eos-Family/ETCnomad-ETCnomad-Puck/ ETCnomad-Puck.aspx
The ETCnomad Puck lighting controller does not support the ETCNet2/EDMX protocol
