Product Description
PLEASE CONTACT US AT 866-457-5937 FOR ALTERNATIVES
ETC ERP-LVD 0-10V Dimming Control Option Kit
0-10V Dimming Control Option Kit. Includes 24 loops of low voltage dimming control.
Relay and dimming - all in one
Relay and dimming - all in one. Whether you're lighting classrooms, restaurants, hotel conference rooms, or another type of space, the Unison Echo™ 0-10V Dimming Controller provides you with on/off functionality for LED drivers and fluorescent ballasts up to 20 amps. Echo 0-10V Controllers are available for single- or dual-zone configurations, allowing for added flexibility in your installation.
Plug-and-play. The installation of your system is easy with the Echo 0-10V Controller. It's ready to go right out of the box - no software or programming required. The added benefit of using Cat-5 cable means that adding more stations or sensors is a breeze, while the Echo 0-10V Controller's flexible infrastructure and topology-free control wiring makes overall setup remarkably stress-free.
The Echo 0-10V Controller can connect to 16 control stations and sensors, and 15 additional power controllers or panels, giving you a top-of-the-line energy- and labor-saving system with a low overall cost and an immediate return on your investment. And with up to 500 meters (or 1640 feet) of control-wire per system, it can reach any location you need.
It's easy being green. Echo was specifically developed with your energy concerns in mind. Keeping green has never been easier - Echo's complete line of products gives you maximum energy savings while adhering to the growing number of industry energy codes, such as ASHRAE 90.1, CA Title 20/24 and IECC, all without breaking the bank.
Echo 0-10V Controllers provide line voltage isolation for each control output. This isolation protects equipment from mains voltage leaks so that equipment can be prepared for any 0-10V driver in the field.
Unison Echo 0-10V Dimming Controllers offer fully-rated 20-amp relays coupled with 0-10V dimming for direct control of compatible LED drivers and fluorescent dimming ballasts. The Controller mounts to fixtures and electrical junction boxes.
APPLICATIONS • Houses of worship • Education • Hospitality • Healthcare facilities • Office buildings • Conference rooms • Meeting rooms • Retail
FEATURES • Single- and dual-zone options • 20A fully-rated relay for use with general purpose, tungsten, fluorescent and LED loads • Fully isolated 0-10V dimming for direct connection to dimming ballasts and LED drivers • 120/277VAC power input • Plug and Play: ready to go out of the box, no software or external programming required • Supports Unison Echo control stations and responsive controls • EchoConnect®: Two-wire topology-free system gives you the freedom to put stations where you need them - Up to 16 Echo control products - Up to 16 Echo output products - Up to 500 meters (1640 feet) of control wire per system
GENERAL • UL and cUL LISTED • Rated for plenum use • Supports Demand Response via EchoConnect
Echo 0-10V Dimming Controller
MODEL DESCRIPTION
- ELD-G2 Echo Single-zone 0-10V Controller
- EDLD-G2 Echo Dual-zone 0-10V Controller
Echo Power Requirements
- EchoConnect: One unit of output power
- Auxiliary Power: Not required
Echo Presets
- Supports 16 Echo Presets
SPECIFICATIONS:
FUNCTIONAL • Control for individual fixtures, zone power and 0-10V dimming for fluorescent ballasts and LED drivers • Plug and Play: ready to go out of the box, no software or external programming required • Interacts with Unison Echo control stations and responsive controls
MECHANICAL • Constructed of injection-molded ABS plastic • Single-zone and dual-zone options • Button interface and LED indicator per zone for configuration • Rotary dials for selection of space and zone number • Half-inch conduit knockout mounted • Mains-voltage and 0-10V wiring exits through knockout mount • EchoConnect wiring exits through side of controller • Optional mounting plate available for applications that require low-voltage wiring to be in conduit • MicroSD for field software upgrades • Mains power input: - 12 AWG Hot - Black - 14 AWG Neutral - White • Relay output: - Zone 1, 12 AWG - Red - Zone 2, 12 AWG - Red/White (Dual-zone only) • 0-10V dimming output: - Zone 1, 22 AWG - Violet and Gray - Zone 2, 22 AWG - Violet/White and Gray/White (Dual-zone only) • EchoConnect control connection: - Control, 18 AWG - Black and White - Ground, 18 AWG - Green/Yellow
ELECTRICAL • 120V-277V, 60Hz power input • Normally Open (NO) 20A fully-rated relay • 0-10vDC ballast control (sink) rated for 100mA maximum, fully isolated from ground • EchoConnect Class 2 control network - Topology-free wiring using Belden 8471 or equivalent and one #18 ESD drain wire - Wiring may be bus, loop, homerun or any combination of these • Up to 500 meters (1640 feet) of control wiring per system • Optional Cat5/5e wiring using Belden 1583A or equivalent - Requires optional Cat5 termination accessories • UL and cUL LISTED • Conforms to UL 508 and UL 2043
THERMAL • Ambient room temperature: -10 to 45°C / 14 to 113°F • Ambient humidity: 5 to 95% non-condensing
