Product Description
ETC ELED2H-AU 240-347 Tunable White Dimming Controller, 240-347VAC, Intensity and CCT
Overview
The Tunable White Dimming controller, model ELED2, is designed for lighting fixtures with adjustable intensity and tunable white color control. Two 0–10 V outputs and a 20 A relay ensure single fixture or entire zone control can easily be accommodated with one controller. The ELED2 delivers versatile control for commercial lighting applications with nationwide energy code compliance
All ELED2 models deliver common lighting control sequences based on occupancy state, switch action, timeclock, gateways, ambient light, and correlated color temperature (CCT) levels.
Echoflex products include preset functionality allowing spaces to be lit with lighting scenes that provide desired light intensity and color temperature. A lockout feature allows timeclocks to schedule a controller’s response to specific sensor types or stations based on time-of-day.
The ELED2 provides control of electrical circuits from 120 VAC through to 277 VAC and the ELED2H operates from 240 VAC to 347 VAC.
Features
- Designed for LED fixtures with two 0–10 V channels delivering dimming and tunable white color temperature control
- Integrated daylight harvesting control supporting open and closed loop applications
- Multiple embedded preset values allow lighting scene recall
- Lockout feature allows masking of sensor inputs based on time-of-day events
- Occupancy state options of automatic partial-ON control or vacancy control with manual ON, partial/full-OFF
- Central Command support for BEMS gateway or timeclock control
- Dynamic CCT set point, dim-to-warm, or manual control of tunable white color temperature LED fixtures
- Pre-linking and pre-commissioning available when sold as a system through Echoflex
- Easy commissioning options include embedded Simple Tap technology plus Garibaldi Pro, Echoflex’s remote commissioning software
- Easy installation on electrical junction boxes with 1/2 in nipple mount
- Energy code compliant
