  • ETC EchoTouch Controller

    • ETC EchoTouch Controller

    MSRP: $1,095.00
    $1,004.00
    (You save $91.00 )
    SKU:
    ETC EchoTouch Controller
    UPC:
    7186A1119
    Condition:
    New
    Availability:
    Lead time is 2 weeks.
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    ETC EchoTouch Controller

    EchoTouch offers compact, stylish, and intuitive touchscreen control of lighting in architectural and smaller entertainment spaces. Combining three powerful capabilities into one elegant device, EchoTouch can: • Act as an interface into a standalone or integrated Unison Echo® control system • Provide status and control of all Echo products • Direct control for DMX/RDM and sACN fixtures and devices EchoTouch shines in all environments, whether in a commercial building with users who need to choose between preset looks, or in an event space to create and recall predetermined looks.

    Features: • Locally program and control Echo zones, presets and sequences • Directly control lights on any system that supports DMX or sACN • 3-gang back box for easy install • 7-inch touchscreen interface • Intuitive and accessible color control • RDM discovery of devices • Black glass front with four bezel colors: Cream, Gray, Black and White

    Color Information: Available in Cream, Gray, Black and White

    EchoTouch offers compact, stylish, and intuitive touchscreen control of lighting in architectural and small entertainment spaces. Combining three powerful capabilities into one elegant device, EchoTouch provides standalone or integrated Unison Echo control. The 7” touchscreen interfaces provides status and control of all connected Echo products, as well as direct control for DMX/RDM, sACN and Art-Net devices. EchoTouch shines in all environments, whether in a commercial building with users who need to choose between preset looks, or in an event space to create and recall looks.

    FEATURES • Supports 80 control channels • Support for playback of 64 presets and 4 sequences • Support for DMX, RDM, sACN, ArtNet and EchoConnect protocols • Control of devices in all 16 Echo spaces • User customized interface • Multilevel security access • PoE or 24 V powered • Mounts to a standard 3-gang back box • EchoConnect: two-wire topology-free system gives you the freedom to easily place stations wherever they are needed

    APPLICATIONS • Small entertainment spaces • Hospitality • Healthcare facilities • Conference and meeting rooms • Lobby spaces • Retail • Houses of worship

    Accessories:

    MODEL DESCRIPTION

    • ETS-LC-_ EchoTouch Locking Cover
    • ETS-SBB EchoTouch Surface-Mount Back Box
    • ETS-LCB EchoTouch Surface-Mount Locking Cover Back Box
    • ETS-RM EchoTouch Rack-Mount Kit

    Echo Power Requirements

    • EchoConnect: One unit of output power
    • Auxiliary Power: 400 mA
    • Notes: 1) Auxiliary power is not required when using PoE 2) An EchoConnect power supply is required when connecting to an Echo Control System

    Echo Presets: Supports 64 Echo Preset

    SPECIFICATIONS:

    FUNCTIONAL • Supports 80 control channels • One universe of output and control of devices in all 16 Echo spaces • Supports playback of 64 Presets and 4 internal Sequences with one active at any time • User customized touchscreen interface with support for layout and naming of: - Seven User pages - Zone faders (up to 11 per page) - Preset, Sequence and Off buttons (up to 30 per page) - Channel and Space Modification buttons - Space Combine buttons - Six user definable utility buttons • Color and White Pickers • Innovative touch-based parameter controls with Reference based Position, Color and Beam palettes • On-board help system • Extensive, searchable fixture library with support for RDM fixture discovery • Two configurable security levels for user access and setup • Adjustable time out options including: dim, off, or user selectable inactivity image

    PROTOCOLS • Support for DMX (ANSI E1.11), RDM (ANSI E1.20), sACN (ANSI E1.31), Art-Net, and EchoConnect protocols • Support for up to 512 simultaneous addresses using any combination of output protocols • EchoConnect output of up to 16 zones • Connects to EchoConnect station bus for use with all Echo control and output products

    MECHANICAL • 7” color multi-touch touchscreen with adjustable backlight • 800 x 480 screen resolution • Cast zinc bexel finished in fine textured powder coat paint available in four standard colors: - Cream (RAL 9001), Gray (RAL 7001), Black (RAL 9004), and White (RAL 9003) • No visible means of attachment • Flush-mount to industry standard 3-gang back box (RACO 697 or equivalent) • Back box for surface mount applications available from ETC • Locking cover available

    ELECTRICAL • RJ45 connector compliant with IEEE 802.3i for 10BASE-T, and 802.3u for 100BASE-TX • Powered using 802.3af for Power over Ethernet - Optional 24 VDC power input for use with non-PoE systems • Pluggable rising clamp screw terminal connector for Auxiliary Power and EchoConnect wiring • Pluggable rising clamp screw terminal or IDC connector for DMX wiring • USB port for firmware maintenance, file transfer, and show file storage

    ECHOCONNECT • Connects via two-wire EchoConnect control network using low-voltage Class 2 wiring - Topology-free wiring over Belden 8471 or equivalent and one #14 ESD drain wire • Supports use of Belden 1583A or equivalent Ethernet control wire when used with IDC termination kit • Wiring may be bus, loop, homerun, or any combination of these • Supports up to 500 m (1,640 ft) of control wiring - Up to 1,000 ft using Cat5

    DMX • Connector designed for use with Belden 9729 (or equivalent) • Optional header included for use with Belden 1583A (or equivalent) • Fully optically isolated from controller electronics • Withstands fault voltages up to 250 VAC

    THERMAL • Ambient temperature: 0°–40° C (32°–104° F) • Ambient humidity: 5–95% non-condensing

    REGULATORY AND COMPLIANCE • cULus Listed • CE compliant • RoHS compliant • WEEE

    Note in 2021 these part #s changed slightly, while the model #s have remained the same.

    These are model #s ETS-1, ETS-3, ETS-4, ETS-5.

    These are part #s 7186A1119-1, 7186A1119-3, 7186A1119-4, 7186A1119-5.

    Other Details

    Warranty Coverage. ETC WILL ONLY BE OBLIGATED TO HONOR THE WARRANTY SET OUT BELOW UPON RECEIPT OF FULL PAYMENT OF THE ORDER. Electronic Theatre Controls, Inc. (“ETC”) warrants to the original owner or retail customer (“Customer”) that during the warranty period defined below, ETC will repair or replace its Products that are defective in materials or workmanship which cause the Product to fail to operate in accordance with ETC’s published specifications for the Product in effect as of the date of shipment, subject to the terms of this limited warranty. The warranty period of box Products shall begin on the date of shipment (“Warranty Start Date”), except the Warranty State Date shall begin on the date of energization for Orders which include energization performed by ETC or an authorized service provider acting on ETC’s behalf. If no energization date is recorded, however, the Warranty State Date shall begin on the date of shipment. The controlling warranty, terms and conditions, and product warranty periods is available at the time of order acknowledgment, either by hard copy or by the PDF document found via the internet link listed on the order acknowledgment as of the date of the order acknowledgment. If ETC shall fail to repair or replace defective Products within a reasonable time after they are returned to ETC, or if ETC shall wrongfully fail to make delivery or shall wrongfully repudiate this contract, then Customer shall be entitled to recover from ETC such part of the purchase price as has been paid by Customer to ETC. The remedy stated in the preceding sentence shall be Customer’s exclusive remedy for any breach, non-delivery, or repudiation by ETC or for any other liability of ETC to Customer. This exclusive remedy shall not be deemed to have failed its essential purpose so long as ETC is willing and able to repair or replace defective Products in the prescribed manner. Warranty Exclusions. This Warranty does not impose any liability or duty upon ETC for: (i) any Product or part of a Product damaged by or subject to accident, negligence, alteration, abuse or misuse by Customer, or any accessories or parts not supplied by ETC; (ii) any damage caused by the unauthorized adjustment, repair or service of the Products by anyone other than ETC or its authorized repair agents; (iii) any damage, to any Product, or part of a Product caused by or due to an act of God, any catastrophe resulting from earthquake, fire, flood, explosion, inability to obtain materials or utilities, or any other cause beyond the reasonable control of ETC. This warranty also does not cover “consumable” parts such as fuses, lamps, color media or components which may be warranted directly to the Customer by the original manufacturer. This Warranty does not extend to items not manufactured by ETC. Freight terms on warranty repairs are FOB ETC factory or designated repair facility. Collect shipments or freight allowances will not be accepted. ELECTRONIC THEATRE CONTROLS, INC.’S STANDARD TERMS AND CONDITIONS OF SALE AND WARRANTY Rev. 6/25/2019 Page 3 of 3 ETC’s sole responsibility under this Warranty shall be to repair or replace at ETC’s option such Products or parts of Products as shall be determined to be defective on ETC’s inspection. ETC, at its option, may perform on-site warranty repairs. If ETC chooses to replace the Product and is not able to do so because it has been discontinued or is not available, ETC may replace it with a comparable product. ETC reserves the right to use new, re-worked, repaired, or refurbished parts in the repair or replacement of any Product covered by this Warranty. ETC will not assume any responsibility for any labor expended or materials used to repair any Products without ETC’s prior written authorization. ETC SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL, GENERAL OR CONSEQUENTIAL DAMAGES, DAMAGES TO PROPERTY, DAMAGES FOR LOSS OF USE, TIME, PROFITS OR INCOME, OR ANY OTHER DAMAGES. The Customer’s obligations during the warranty period under this Warranty are to notify ETC within one week of any suspected defect and to return the Products prepaid to ETC at ETC’s factory or authorized service center. The one week notice period does not apply to claims for shortage or damaged Products. This written Warranty is intended as a complete and exclusive statement of the terms thereof. Prior dealings or trade usage shall not be relevant to modify, explain or vary this Warranty. Acceptance of, or acquiescing in, a course of performance under this Warranty shall not modify the meaning of this Warranty even though either party has knowledge of the performance and a chance to object. THIS LIMITED WARRANTY IS THE ONLY WARRANTY APPLICABLE TO THE EQUIPMENT AND REPLACES ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SPECIFICALLY, EXCEPT AS PROVIDED HEREIN, ETC UNDERTAKES NO RESPONSIBILITY FOR THE QUALITY OF THE PRODUCT OR THAT THE PRODUCT WILL BE FIT FOR ANY PARTICULAR PURPOSE FOR WHICH CUSTOMER MAY BE BUYING THE PRODUCT. ANY IMPLIED WARRANTY IS LIMITED IN DURATION TO THE WARRANTY PERIOD. NO ORAL OR WRITTEN INFORMATION, OR ADVICE GIVEN BY ETC, IT’S AGENTS OR EMPLOYEES, SHALL CREATE A WARRANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS LIMITED WARRANTY. United States, Latin American, and Canadian Dealers: ETC Products forwarded outside of the United States, Latin America and/or Canada will only be covered by the Warranty Statement applicable to the region in question, and therefore this Warranty may or may not apply. Please contact ETC for the applicable warranty statement.
