Product Description
ETC ARCN100 Navis 100 Luminaire 3000 K 60 Degree Offset
Overview
The compact Navis 100 Adjustable luminaire is ideally suited for recessed installations in areas that require short- to medium-throw illumination.
The Navis 100 accepts a low voltage DC connection and is designed for a direct connection to an external F-Drive LED driver, see separate datasheet for more details. In conjunction with the driver unit, the luminaire can be dimmed using a DMX/RDM input.
Navis has been specifically developed for architectural lighting applications where high-quality optics and extremely accurate and smooth dimming are required.
Installation couldn’t be easier. With simple, wind-down clamps, Navis 100 can be installed in ceiling thicknesses of 0.5–20 mm (0.02–0.78 in).
The use of external driver technology removes critical components from recessed ceiling spaces and places them in accessible electrical rooms/cabinets.
Features
- High-grade, field-changeable TIR optics and accessories
- Stepless smooth dimming
- Convection cooled
- Fan-free, silent operation
- Multiple color-temperatures
- RGBW color-mixing option
- Remote power-supply for improved accessibility
- Variable ceiling-thickness mounting mechanism
- Locking 360° rotation and 30° tilt
