Product Description
elektraLite EYEB 5IN1 10D 7-12w 5-in-1 (RGBAW) LED 10° Beam Spread
Overview
A powerful fixture in a compact body, the elektraLite eyeBall-A is ready to solve your solutions both big and small.
At the heart of the elektraLite eyeBall-A are seven 12-watt 5-in-1 LED’s, consisting of a red, green, blue, white, and amber component. The 5-in-1 LED uses diffraction lensing, eliminating “rainbow” color spots which are typical when individual LED’s are exposed in lighting a cyc or similar background. By mixing color internally, the eyeBall-A’s sophisticated diffraction lensing system provide true, blended, single-color output. Because of this, the white is perfectly blended and balanced, so as not to emit a blue-white so often seen in LED fixtures. Three beam angles are available 10°, 25° and 40°.
More than a stage and key/highlight fixture, the elektraLite eyeBall-A can also be used as a truss warmer a shin kicker or even as a house light just as easily and effectively. With a convenient and compact strong double-yoke, mounting options are limitless.
A user-friendly onboard control interface allows for multiple control options in addition to DMX, including RGB, strobe, and console-free master/slave operation. Plug-and-play functionality is built right in, RDM capability is now also included! Static control capability means house light control is simple and effective and at any time DMX control may also be used during a show presentation with static control resuming after the show.
The eyeBall-A has both power in and thru for easy “daisy chaining” and includes an interconnect jumper cable. The DMX connectors (both in and thru) are 5-pin XLR, however 3>5 pin and 5>3 pin turnarounds are provided for maximum flexibility.
The eyeball-A is ETL certified for peace of mind and safety.
Accessories included with each eyeBall are as follows:
- double‐yoke
- (1) 24” IEC power cable with Edison connector
- (1) IEC extension cable
- (1) 5‐pin DMX extension cable
- (1) 3>5 pin DMX turnaround
- (1) 5>3 pin DMX turnaround
Features
- 5-in-1 LED technology; utilizing seven 12-watt 5-way LED’s
- Compact design fits perfectly in 12” box truss
- Flicker‐free on camera operation
- Strong double yoke allows for floor mount or hanging, with low‐profile adjustment handles for a slim, tight contour
- Variable adjustable speed strobe effect, from 0.3 to 25 FPS
- Variable, adjustable fans can be set to run automatically, manually, turned off, or controlled via DMX
- RGBWA 5-in-1 LED’s, including 3,200 to 5,000K white, for crisp, bright, balanced white light
Specifications
Power Consumption – 100 watts (0.9A)
Electrical – multi-voltage; AC 100-240V – 50/60Hz IEC power (in and thru) connectors
Housing – high temperature black polycarbonate
Materials – corrosion resistant hardware
Yoke – rigid flat steel
Light Engine – seven 12-watt 5-in-1 LED emitters
Refresh Rate – >1,200Hz
CRI – 92
Optics / Lensing(s) – Diffraction Lensing
Control – DMX-512A (in and thru) via 5-pin XLR 3>5 & 5>3 pin turnarounds included
Certifications – ETL listed
Physical – L 8.6″ W 6.5″ H 6.5″
Weight – 4.6 lbs / 2.0 Kgs
