Product Description
Electro-Voice TX1181 18" 500W Passive Subwoofer, Black
Overview
These high performance speakers feature EV's SMX woofers, which yield extraordinarily low levels of distortion without sacrificing sensitivity. The backbone grille design is aesthetically remarkable while also damage-resistant, and the input panels and handle were ergonomically designed for maximum comfort and utility. Steep slope analog crossovers with elliptical filters provide up to 36dB per octave slopes, greatly reducing acoustic transducer interaction for better sound and higher power handling. Finally, the floor monitors feature a patent-pending SST (Signal Synchronized Transducers) design which utilizes a split baffle layout, allowing the enclosure to be more compact and yielding near-perfect driver phase summation. Tour X speakers are ideal for bands, entertainers, DJ, karaoke, speech reinforcement, and more.
Specifications
- Frequency Response (-3dB): 50-160 Hz
- Frequency Response (-10dB): 45 – 700 Hz
- Recommended High-Pass Frequency: 30 Hz
- Sensitivity @ 1W/1m: 100 dB
- Max SPL/1m (calculated): 132 dB
- System Power Handling (continuous/program/peak): 500/1000/2000 Watts
- LF Transducer: EVS18S
- Nominal Impedance (Passive): 8 Ohms
- Minimum Impedance: 7.5 Ohms
- Enclosure Material: Plywood and MDF with EVCOAT
- Color: Black
- Flying: No
- Input Connections: Parallel Neutrik® NL4
- Internal Crossover: Yes
- Speaker Type: Subs
- Net Weight: 74.52 lbs.
- Dimensions (HxWxD): 30.28" x 17.28" x 23.27"
