Product Description
Electro-Voice OM-1 OMNEO Card for Dante Audio Transport
Overview
Designed around OCA (Open Control Architecture) Bosch Building Technologies' OMNEO is a public standards-based media networking architecture that promotes device interconnectivity. This full-duplex (simultaneous two-way) interface card joins OMNEO and Dante protocols for Dante audio transport on an OMNEO network.
Features
- Gigabit Ethernet Interface - 1000 Mbit/s full-duplex Ethernet Interface, IEEE 802.3u compatible
- Secondary Gigabit Ethernet Interface - Second Ethernet Interface for the connection of a redundant network to establish fault-tolerant systems
- Status LEDs - Link, Activity and Gigabit active status indication for each Ethernet interface
- EN 54-16 and ISO 7240-16 system certification
Specifications
- Supply voltage/current: +3.3 V DC / 860mA+5 V DC / 60mA
- Ethernet connectors (Primary / Secondary): 100/1000 Mbit/s, RJ-45, integrated transformer isolation
- Sampling rate: 48 kHz
- Data format: 24 Bit
- Audio channels: Up to 16 - 16 at 48 kHz
- Audio flows: Up to 16 - 16 simultaneous audio streams
- Latency across network: 5 ms (typically)
- Dimensions (WxHxD): 89 x 27 x 92 mm
- Weight: 75 g
- Operating temperature: -5°C to +45°C (+23°F to +113°F)
- Storage and transport temperature: -20°C to +70°C (-4°F to +158°F)
- Humidity (non-condensing): 5% to 90%
- Altitude: Up to 2000 m
