Product Description
Electro-Voice MFX-15MC 15" Multiuse Coaxial Monitor Speaker
Overview
Designed for musicians, bands, small venues, and rental houses, the black Electro Voice MFX-15MC 15" Multi-Use Coaxial Monitor Speaker is a compact and versatile monitoring system that's designed to be a live soundstage monitor or short-throw full-range sound-reinforcement speaker, and is appropriate for a wide range of permanent installations. The design of the enclosure ensures a low stage profile to preserve sight lines. The input panel is recessed into the rear of the speaker, protecting connectors within the cabinet envelope. The panel includes NL4 input and loop-through connections, along with a passive / bi-amp switch.
The MFX-15MC has 500W of continuous (3500W peak) power handling. The 15" woofer and 3" compression driver combine for a frequency response of 52 Hz to 18 kHz with a maximum 136 dB SPL. The coaxial design ensures a phase accurate output with both drivers in alignment for the best possible sound. The constant directivity waveguide is rotatable, offering more flexibility when deploying. The Baltic birch plywood enclosure has a black EV Coat and a powder coated steel grille, great for surviving the rigors of on-the-road wear and tear.
Features
- Floor Wedge or Main Speaker
- 15" Woofer, 3" Compression Driver
- 500W Continuous Power Handling
- Frequency Response: 52 Hz to 18 kHz
- 136 dB Max SPL
- 60x40° Rotatable Horn
- 8 Ohms for Passive and Bi-Amp
- Coaxial Design for Phase Accurate Output
- NL4 Input and Thru
- Baltic Birch Enclosure with EV Coat
Specifications
Enclosure Type | |
Total Power Capacity | |
Constant Voltage / Transformer Taps | |
System Impedance |
HF Driver | |
MF Driver | |
LF Driver | |
LF Voice Coil |
Frequency Range | |
Frequency Response | |
Maximum SPL | |
Coverage Angle | |
Speaker Sensitivity |
Audio I/O |
Phase Adjustment |
Color | |
Mounting | |
Mounting/Monitor Angle | |
Handles | |
Environmental Resistance | |
Construction Material | |
Dimensions | |
Weight |
