Product Description
Electro-Voice ETX-15SP-US Powered Subwoofer
Features
- 15-inch DVX woofer for maximum punch
- 1800 W Class-D power amplifier with integrated FIR-Drive DSP
- 134 dB peak SPL
- Special DSP preset for true cardioid performance across the full operating bandwidth
- Combo pole cup (insert and threaded) for use with the ETX Powered Loudspeaker full range models
- Removable casters
Specs
Frequency Response (-3 dB) |
37 Hz - 150 Hz¹ |
Frequency Range (-10 dB) |
32 Hz - 180 Hz¹ |
Maximum SPL |
134 dB peak² |
Power Rating |
1800 W |
LF Transducer |
DVX3159A 380 mm (15 in) |
Low Pass Frequency |
Adjustable 80 Hz, 100 Hz, 120 Hz, 150 Hz |
Connectors |
(2) XLR/TRS Combo Jack and (2) XLR link Output |
Enclosure |
18 mm, 13-ply birch plywood with EVCoat |
Grille |
16AWG steel with powdercoat |
Dimensions (H x W x D) |
471 mm x 576 mm x 825 mm (19 in x 23 in x 32 in) |
Dimensions (H x W x D) |
without casters ,471 mm x 576 mm x 692 mm (19 in x 23 in x 27 in) |
Net Weight |
41.7 kg (91.9 lb) |
Shipping Weight |
46.8 kg (103.2 lb) |
Power Consumption |
100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A³ |
¹ Half space measurement using the music DSP preset and 150 Hz low pass.
² Maximum SPL is measured at 1 m using broadband pink noise at maximum amplifier output.
³ Current rating is 1/8 power.
