Product Description
Electro-Voice CPS8.5 120V 500 Watt 8‑Channel Amplifier
Overview
The Electro-Voice CPS8.5 amplifier offers eight independent Class-D Variable Load Drive (VLD) amplifier blocks, each one capable of delivering up to 500 Watts into Low-Z or High-Z loads. Per default, each channel can be configured individually for max. power output into either 2 Ω, 4 Ω, 70V- or 100Vnetworks without involvement of any output transformers.
Being designed for professional audio installation market, special care was taken for long term cost of ownership parameters: In addition to remarkably low current consumption and heat dissipation, the CPS8.5 provides remote standby switching with just 5 Watts consumption in standby mode. An optional remote control module RCM-810 provides control and supervision features via IRIS-Net, including monitoring of amplifier status and real time load supervision. In addition, via RCM-810 the Variable Load Drive characteristics can be set for max. power output into any load between 2 Ω and 10 Ω, in steps of 0.1 Ω.
Features
- 8 x 500 W ▪ High Efficient Class-D Design
- Optimized for permanent installation
- Optional Remote Control Module (RCM-810)
- 2 U Rack Space
