Product Description
Elation Seven Par 19IP 19 x 25W IP65 Par Wash
The SEVEN PAR 19IP is an IP65 outdoor rated seven color par wash luminaire with (19) 25W 7-in-1 RGBAW + Lime + UV LEDs (Red, Green, Blue, White, Amber, Lime, and a 395nm UV) producing up to 9,300 total output lumens and 90CRI. Features include individual hue, saturation, and intensity control, RGB + seven color 3 channel DMX mode, smooth color mixing, 12 internal programs with speed and fade control, 64 unique 7-color macros, selectable dimming curve modes, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, DMX and RDM (Remote Device Management) protocol support, IP65 rated 5pin XLR and power in/out connections, dual adjustable yoke / floor stand, multiple unit power linking, OLED menu display with a 4-button control panel, a multi-voltage universal auto switching power supply (100-240v), and a rugged powder coated die-cast aluminum exterior. Gel frame and gel frame holder included, optional 4-leaf barn door available.
Features
- IP65 Outdoor Rated Seven Color Par Wash Luminaire
- (19) 25W 7-in-1 RGBAW + Lime + UV (395nm) LEDs
- 9,300 Total Output Lumens | 90CRI
- Individual Hue, Saturation, and Intensity Control
- RGB + Seven Color 3 Channel DMX Mode
- Smooth Color Mixing
- 12 Internal Programs with Speed and Fade Control
- 64 Unique 7-Color Macros
- Selectable Dimming Curve Modes
- Adjustable LED Refresh Rate + Gamma Brightness
- Flicker Free Operation for TV and FILM
- DMX and RDM Protocol Support
- IP65 Rated 5pin XLR and Power In/Out
- Dual Adjustable Yoke / Floor Stand
- Multiple Unit Power Linking
- Rugged Powder Coated Die-Cast Aluminum Exterior
- Gel Frame and Gel Frame Holder Included
- Optional 4-Leaf Barn Door Available
Specifications
SOURCE
PHOTOMETRIC DATA
EFFECTS
COLOR
CONTROL / CONNECTIONS
SIZE / WEIGHT
- (19) 25W 7-IN-1 RGBAW + Lime + UV (395nm) LEDs
- 50,000 Hour Average LED Life*
- *Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- 9,300 Total Lumen Output | 90CRI
- 10,551 LUX 981 FC @6.6’ (2m) (Full ON)
EFFECTS
- Individual Hue, Saturation, and Intensity Control
- RGB + Seven Color 3 Channel DMX Mode
- 12 Internal Program Macros with Speed and Fade Control
- 64 Unique 7-Color Macros
- Selectable Dimming Curve Effects
COLOR
- RGBAW + Lime + UV (395nm)
CONTROL / CONNECTIONS
- (7) DMX Channel Modes (15 total channels)
- DMX and Manual Control
- 4 Button Control Panel
- 180° Reversible OLED Menu Display
- Adjustable Refresh Rate (900-25,000 (Hz)
- Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
- RDM (Remote Device Management) Protocol Support
- IP Rated 5pin DMX and Power In/Out
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 14.0” (357mm)
- Width: 14.6” (371mm)
- Vertical Height: 11.2” (284mm)
- Weight: 25.0 lbs. (11.3kg)
GEL FRAME
- Length: 12" (305mm)
- Vertical Height: 12" (305mm)
- Inner Diameter: 9" (229mm)
ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 500W Max Power Consumption
- 5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
- CE | cETLus | IP65
