Product Description
Elation Seven Batten 72 60 x 25W Batten Wash
The SEVEN Batten 72 is a seven color 6 foot (1.8m) long batten wash luminaire with (60) 25W 7-in-1 RGBAW + Lime + UV (395nm) LEDs. Features include individual hue, saturation, and intensity control, special RGB SEVEN 3 channel mode (RGB + dynamic white, amber, lime, and UV), 10 pixel mapping zones with pixel flip mode, smooth color mixing, 12 internal programs with speed and fade control, 64 unique 7-color macros, selectable dimming curve modes, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, DMX Art-Net, Kling-Net, and RDM (Remote Device Management) protocol support, 3/5pin DMX, RJ45 ethernet, and Locking Power Cable in/out connections, dual 220° manual tilt adjustable mounting brackets, OLED menu display with a 4-button control panel, a multi-voltage universal auto switching power supply (100-240v), a rugged powder coated die-cast aluminum exterior, and an integrated gel / frost filter slot.
Features
- 6 Foot (1.8m) Seven Color Batten Wash Luminaire
- (60) 25W 7-in-1 RGBAW + Lime + UV (395nm) LEDs
- Individual Hue, Saturation, and Intensity Control
- Special RGB SEVEN 3 Channel Mode (RGB + Dynamic White, Amber, Lime, UV)
- 10 Pixel Mapping Zones with Pixel Flip Mode
- Smooth Color Mixing, Internal Programs with Speed and Fade Control
- 64 Unique 7-Color Macros
- Selectable 16-bit Dimming Curve Modes
- Adjustable LED Refresh Rate + Gamma Brightness
- Flicker Free Operation for TV and FILM
- Art-Net, Kling-Net, and RDM Protocol Support
- 220° Manual Tilt Adjustable Mounting Brackets
- Rugged Powder Coated Die-Cast Aluminum Exterior
- Integrated Gel / Frost Filter Slot
Specifications
SOURCE
- (60) 25W 7-IN-1 RGBAW + Lime + UV LEDs
- 50,000 Hour Average LED Life*
- *May vary depending on several factors including but not limited to:
- Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
EFFECTS
- Individual Hue, Saturation, and Intensity Control
- Special RGB SEVEN 3 Channel DMX Mode (RGB + Dynamic White, Amber, Lime, UV)
- 10 Pixel Mapping Zones with Pixel Flip Mode
- 12 Internal Program Macros with Speed and Fade Control
- 64 Unique 7-Color Macros
- Selectable 16-bit Dimming Curve Mode
COLOR
- RGBAW + Lime + UV (395nm)
CONTROL / CONNECTIONS
- 10 DMX Channel Modes (78 total channels)
- DMX and Manual Control
- 4 Button Control Panel
- 180° Reversible OLED Menu Display
- Adjustable Refresh Rate (900-25,000 (Hz)
- Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
- Art-Net, Kling-Net, and RDM) Protocol Support
- 3/5pin DMX, RJ45 ethernet, and Locking Power Cable In/Out
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 72.0” (1828.8mm)
- Width: 4.5” (114.3mm)
- Vertical Height: 9.0” (228.6mm)
- Weight: 58.0 lbs. (26.3kg)
ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 1000W Max Power Consumption
- 14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS
- CE | cETLus | IP20
