Product Description
Elation Prisma Par 20 IP65 Rated Exterior UV Wash Par
PRISMA PAR 20 is an exterior IP65 rated UV wash par luminaire that produces 365nm peak true UV output with zero visible light. Features include a 20 degree narrow beam angle, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control, dual adjustable mounting yokes, a durable aluminum housing, IP65 DMX 5pin XLR and locking power in/out connections.
Features
- IP65 Rated Exterior High-Power UV Wash Par Luminaire
- 20 Degree Narrow Beam Angle
- 365nm Peak True UV Wavelength
- Zero Visible Light Output
Specifications
SOURCE
- (12) 2W High Power UV Diode LEDs
- 20,000 Hour Average LED Life*
*Test lab conditions. May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- 20 Degree Narrow Beam Angle
- 365nm True UV Peak Wavelength
EFFECTS
- High Speed Electronic Strobe
- Variable Dimming Curve Modes
CONSTRUCTION
- Rugged IP65 Rated Housing
- Dual Adjustable Mounting Yokes
CONTROL
- Multiple DMX Channel Modes
- Onboard 4 Button Touch Control Panel
- DMX-512 and RDM Protocol Support
CONNECTIONS
- Locking 5pin XLR Connector In/Out
- IP65 Locking Power Connector In
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 8.58 in. (218mm)
- Width: 5.90 in. (150.6mm)
- Vertical Height: 9.72 in. (246.6mm)
- Weight: 5.29 lbs. (2.40kg)
ELECTRICAL
- AC100-240V 50-60Hz
- 27W Max Power Consumption
THERMAL
- 14°F to 113°F (-10°C to 45°C)
- Air Cooled
APPROVALS / RATINGS
- CE | cETLus | IP65
