Product Description
Elation PALADIN Brick IP65 360W RGBW Floodlight
The PALADIN Brick is a compact and powerful outdoor flood light for a wide variety of applications. Using 24x15W RGBW cells it provides a total output of up to 8,200 lumens. Certified to IP65 it features a rugged design with a solid build quality, eliminating the need to worry about dust and water ingress. IP rated connections make it an ideal product to illuminate large areas of any outdoor event with vibrant and powerful colors. It can be operated standing on the floor or be hung in any orientation using the provided omega brackets. Available cell control and strobe features make the PALADIN Brick also a versatile effects fixture or audience blinder.
Features
- 360W RGBW Flood Light
- 3x2 Cell Control
- Rugged IP65 Design for Outdoor Events
- Floor Standing or Mountable in any Orientation
Specifications
SOURCE
- 24x 15W RGBW LED Emitters
- 50,000 Hour Average LED Life*
- *Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA
- 6,000K Color Temperature
- 8,200 Total Lumen Output
- 14.1° Beam 25.4° Field Angle (without diffuser)
- 25.3° Beam 50° Field Angle (with diffuser)
CONTROL / CONNECTIONS
- 11 DMX Channel Modes (56 Total Channels)
- 3x2 Cell Control
- Manual Tilt Adjustment
- DMX, RDM Protocol Support
- Standalone and Primary/Secondary Operation
- 4 Button OLED Control Display
- Elation’s E-FLY™ Internal Wireless DMX Transceiver
- IP65 5pin DMX In/Out
- IP65 Power In/Out
- With Wired Digital Communication Network
SIZE / WEIGHT
- Length: 17.2” (438mm)
- Width: 5.8” (147mm)
- Height: 11.3” (286mm)
- Weight 21 lbs (9.5kg)
ELECTRICAL / THERMAL
- AC 100-240V - 50/60Hz
- 390W Max Power Consumption
- 5°F to 113°F (-15°C to 45°C)
APPROVALS / RATINGS
- CE | cETLus | IP65
