Product Description
Doug Fleenor Design WP-RJ-ESTA Single Gang RJ-45 Connectors DMX Wall Plate
The DMX512 Wall Plates, from Doug Fleenor Design, are an attractive solution for DMX512 inputs and outputs, and are suitable for use in audience spaces. Manufactured from solid aluminum, the plates are black anodized over a grained finish with machined nomenclature. Custom colors and nomenclature are available on request. The plates fit standard North American single gang electrical boxes and require 1 3/8 inches of depth inside the box.
Specs
Inside connector: 5 position screw terminal block
Outside connector: Gold plated 5 pin XLR (Neutrik D-1 series), 3 pin optional
Connector sex:
- Input plate (model WP-I): Male
- Output plate (model WP-O): Female
Color: Black anodized on grained surface with silver nomenclature
Size and weight: 4.5”h x 2.75”w x 1.8”d, 5 ounces
Panel thickness: 0.2”
Depth behind panel: 1.375”
