Product Description
Doug Fleenor Design RAD RDM Remote Addressing Device
The Remote Addressing Device (model: RAD) is used to set the DMX address of compatible products using DMX/RDM. RDM (Remote Device Management) is an enhancement to DMX512 which allows status information and parameters (such as the DMX address) to be communicated over the DMX link.
When powered normally, the RAD defaults to setting the DMX address. However, when the RAD is powered while holding the button below the ones digit on the display, it will show the letter “P” indicating that it will be setting the personality of the selected RDM device.
Specs
Connector: Gold plated 5-pin female Neutrik XLR
Connector Pin Out: 1 – DMX512 Common 2 – DMX512 Data3 – DMX512 Data+ 4 – N/C 5 – N/C
User Controls: 1's,10's,100's, LAST and NEXT buttons
Indicators: Three digit 7-segment LED display
Power: Standard 9V battery
Color: Yellow with black nomenclature
Size & Weight: 4"H × 2"D × 2.5"W, ½ pound
