Doug Fleenor Design NODE 4 4 Port Ethernet to DMX Interface
The NODE4 is an Ethernet to DMX interface. It accepts E1.31 sACN, draft sACN, Art-Net, Strand ShowNet, and KiNET. There are four fully isolated DMX ports. Each port can be configured as either an input or as an output. All of the data connectors can be mounted on either the front or rear panel. Their location can be changed in the field to accommodate fixed or touring installations.
The factory default configuration covers most applications. An easy to use control panel gives access to all network settings if a change is needed. The back lit 2 line by 20 character LCD and LED indicators give quick status feedback.
Configuration is a breeze, just choose what you want to setup by selecting the port or network adapter via the “SELECT” keys. Use the arrow keys to find the option you want to change hit “ENTER” use the arrows to change the value and “ENTER” again to save. You can use “BACK” at any time to disregard changes and return to the above menu.
The NODE4 features a universal input power supply and a rugged enclosure. An optional rack mounting kit is available (model RK16-1). Holes are provided for easy truss mounting using a C- clamp or half-coupler.
Main Specs
Power input: 6W, 100 to 240 VAC 50/60 Hz
Color: Front, Back: Black Top, Bottom, Sides: Silver Hammertone
Size and weight: 1.7”H × 10.375"D × 16.5"W, 6 pounds
Port Specs
Port circuit:
- EIA-485 transceiver with 120 ohm fail safe termination between +Data and -Data
- NOTE: This product uses a slew-rate-limited output drivers. Slewrate-limited drivers minimize EMI and reduce reflections caused by improperly terminated cables.
Input signal: 0.2 volts minimum, 12 volts maximum
Output signal: 1.5 volts (minimum) into 120 Ohm
Termination Connectors: Gold plated 5 pin XLR (typically four female connectors, male on request)
Port protection: +60V continuous, +15KV transient
Isolation: 600 volts
Ethernet Specs
Ethernet Circuit: 100BASE-TX Fast Ethernet, Auto detects if crossover or regular cable is used, and speed negotiation up to 100Mbits.
Connector: Neutrik Ethercon
Isolation: 1500 Volts
Network Protocols: E1.31 sACN, draft sACN, Art-Net, Strand ShowNet, KiNET
