Doug Fleenor Design ES2ETHER 2-Button Wall Mounted DMX Controller - 4 Universe
The Entry Station Two Ethernet ES2ETHER) wall station plays back snapshots of sACN (E1.31) on four universes. The simple front interface allows the user to control 2,048 individual slots with the push of a button. Static snapshots from any sACN capable console record into the ten presets. Snapshot play back may be used as an alternative to a more complex console, or operate along with that same console. Various lockout topologies make the ES2ETHER ideal in venues requiring untrained users to control fixtures typically accessed by a more complex console. The ES2ETHER supports Power over Ethernet (PoE – 802.3af) or a 24-48VDC power input. Station configuration takes place on a rear facing user interface. Multiple stations may act as remote stations with our Preset 10 Ethernet (model PRE10ETHER-A), and stations operating on different universes may operate on the same Local Area Network (LAN).
Specs
Input: E1.31 sACN – 4 Universes – 10/100 Mbps Ethernet
Output: E1.31 sACN – 4 Universes – 10/100 Mbps Ethernet
Connector: RJ45
Indicators:
- Two Green Illuminated Button Caps
- One yellow Fade time LED
- One red Signal/Record LED
User Controls:
- Two Preset Select Buttons
- One Recessed Record Button
- One Rotary Encoder with Knob
- One Graphical LCD Screen
Options Jumpers: All jumpers installed at ship time
Power Input: 802.3af Power over Ethernet or Auxiliary 24-48 VDC 150mA
Color: Black anodized with silver engraved nomenclature
Size:
- Faceplate: 4.5”H × 0.2”D × 4.6”W
- Faceplate rear inset: 4.15”H × 0.1”D × 4.25”W
- Electrical box minimum inside dimensions: 2.9”H × 1.4”D × 3.6”W
