Doug Fleenor Design DMX96ANL 96-Channel DMX to Analog Converter - 0-10V Output

The DMX to Analog Converter decodes 96 consecutive DMX512 channels to 0-10 volt output. The starting address is selected by an easy to read (and set) three digit push-wheel switch. The switch is mounted on the front panel along with indicators for power, signal, and an output 1 mimic. The DMX in and through connectors and the four female DB-25 output connectors are located on the back panel. All connectors feature gold plated contacts. The output pinouts are easy to remember with the pin number equaling the output number, pin 25 being common. The DMX512 input is optically isolated from the outputs and is protected against miswiring up to 120 volts. The (defeatable) hold feature holds the last look indefinitely upon loss of DMX. A test feature brings any output to full by setting the front panel switch to 601 - 696.

Features

• Input is electrically isolated from output
• Input is protected by transorb diodes
• Input has self resetting "fuses"
• Outputs are current limited
• Outputs are diode protected
• Output circuits are socketed
• DMX starting address is a decimal switch
• Address switch is on the front panel
• Input and output pinouts are printed on the converter
• Gold plated Neutrik 5 pin connectors
• All integrated circuits are socketed
• Uses 2500 Volt optical coupler
• 15 mA drive current
• Power, input, and output indicators

Specs

Input baud: DMX512: 250 Kb/s, CMX: 152.6 Kb/s

Input circuit: EIA-485 receiver with series 100 ohm PTC self resetting "fuses" clamped to +/- 7 volts by four low capacitance transorb diodes

Input signal:

• 0.5 volts minimum, 12 volts maximum
• Input can withstand up to 120 volts without damage, transients up to 5KV

Output circuit:

• LM6134 quad op amp configured to source or sink current.
• Optional 1N4004 series diodes for current sourcing-only applications.

Output signal:

• 0 to 10.1 volts positive DC into 2000 ohm load
• Outputs cannot withstand high negative voltages

Max. output current: 10 mA per output, 120 mA total all outputs (360 mA total on 96 out version)

Input/output isolation: Greater than 500 volts

Throughput delay: Less than .005 seconds (DMX input change to analog output change)

DMX512 connectors: Two gold plated 5 pin Neutrik D-1 Series (male input, female pass through) (All five pins are wired on the pass through)

Analog connector:

• Female DB-25 with gold plated pins
• Pin number equals output number, pin 25 is output common
• For output connectors 2 – 4, add 24, 48, or 72 to pin number

Power input: 90 - 125 volts, 50/60 hertz, 10 watts (180 - 250 volts optional)

Color: Silver anodized aluminum

Size and Weight: 1.7”H × 8.0"D × 16.7"W, 4.5 pounds (19" adapter available)
