Product Description
Doug Fleenor Design DMX6REL15A 6-Channel DMX Relay Pack - 120VAC
Doug Fleenor Design makes a series of Relay Packs that are controlled by DMX512. These six channel units are designed to switch up to 15 amp line voltage loads and are built with 30 amp relays for robust performance. Line voltage input is on an 18" 12/3 SJ pigtail(s) fitted with 15 amp parallel blade plug(s). Model DMX6REL15A has one line in pigtail. Model DMX6REL30A has two line in pigtails (one for relays 1-3, one for relays 4-6). Switched line outputs are on chassis mounted 15 amp parallel blade receptacles.
Doug Fleenor Design Relay Packs use dry contact air-gap relays. These relays have advantages and disadvantages over the solid state relays found in dimmer packs. Solid state relays can be switched on and off rapidly with no wear, but generate heat and leak current even when in the off position. Air-gap relays do not require cooling and do not leak current, but due to their mechanical design have a finite life span. Our relay packs should be used where a true off condition is required (no voltage, no current). They should not be used in applications where they will be turned on and off rapidly such as in chase lights. Ideal applications include fog machines, power to moving light fixtures, motorized disco effects, strobe lights, fans, etc.
Specs
Certification: ETL Listed to the UL 508 standard
Input signal: 250 Kilobaud, 0.2 volts minimum, 12 volts maximum
Input circuit: ESD protected EIA-485 transceiver (LT1785)
Input connector: Gold plated 5 pin male (Neutrik D-1 series)
Input pass through: Gold plated 5 pin female (Neutrik D-1 series). All five pins are passed through.
Power input: 120 VAC, 50/60 hertz, 2 watts (plus load)
Power input plug: NEMA type 5-15P dead front plug
Power input rating: 15 amps per line input pigtail
Power output: Input power is switched to output
Power output socket: Nylon NEMA type 5-15R receptacle
Power output rating: 15 amps per output. Maximum total load is limited by input rating
Output device:
- Omron G8PT
- Mechanical life: 10,000,000 operations minimum
- Electrical life: 300,000 operations minimum at 5 Amps
- 125,000 operations minimum at 15 Amps
Environmental: 0-40° C (32-104° F), 10-90% humidity, non-condensing
Color: Top, bottom and sides: Silver hammer tone. Front and back: Black
Size and weight: 1.7”H × 6.5"D × 16.5"W, 5 pounds (optional 19” rack adapter # RK16-1)
