Product Description
Doug Fleenor Design DMX2D54 1-Channel DMX to D54 Converter
The DMX to D54 interface converts DMX512 into the 384 channels of Strand D54. All connectors feature gold plated contacts. DMX512 is received via a 5 pin male XLR connector. The Strand D54 outputs via a 3 pin female XLR connector. A "pass-thru" 5 pin female XLR is also provided for the DMX signal. LED indicators display DMX input signal, power and a Mimic of Strand D54 channel one. A three digit thumbwheel switch is provided to set the starting address. A test feature allows bringing any output to full by setting the front panel switch to 601 - 984.
