Product Description
dBTechnologies IS8SW Passive IP 32 8’’ Subwoofer, White
Overview
As for the lower end, IS series is comprised of two passive subwoofers, respectively equipped with a 1x8" or a 1x12" woofer.
The compact size of both boxes is ideal when it comes to integrate a low-end extension cabinet in a venue, without dragging too much attention to it.
Needless to say the keyword here is: ease of installation and unobtrusiveness. That's why each single system in IS series comes with a smooth design
Features
- 200W RMS power handling with an 8-inch woofer and 2-inch voice coil for deep and controlled bass.
- Compact design (230mm x 470mm) for easy integration into small or tight spaces without sacrificing performance.
- Delivers a frequency response down to 50 Hz, providing strong low-end reinforcement for various audio applications.
- Maximum SPL of 116 dB, ensuring powerful sound output for small to medium-sized venues.
Specifications
Technical Data
- Speaker Type: Passive Subwoofer
Acoustical data
- RMS Power: 200 W
- Peak Power: 800 W
- Frequency Response [-6 dB]: 50 Hz - custom LPF
- Impedance: 8 Ohm
- Sensitivity 1W@m: 87 dB
- Max SPL: 116 dB
- LF: 1x 8", 2" v.c.
Input
- Connections: Phoenix
Mechanics
- Housing: Plywood, water-painted coating
- Rigging points: 16x M8 pickup point
- IP rating: IP 32
- Width: 230 mm (9.1 in)
- Height: 470 mm (18.5 in)
- Depth: 330 mm (13 in)
- Weight: 10 kg (22 lbs)
