Product Description
dBTechnologies IS6T-WP_W Passive IP 55 Wooden Speaker
Overview
IS6T-WP is the compact and rugged coaxial speaker for indoor and outdoor installations.
Equipped with a 6.5'' coaxial component, it is a compact, highly versatile cabinet designed primarily for background music.
Simple and robust, it is an optimal solution for indoor and outdoor sound reinforcement through a quick installation guaranteed by the included bracket, invisible mounting points, and a IP55 protection. Additional connection versatility is supported by various dedicated accessories.
Features
- PASSIVE 2-WAY COAXIAL SPEAKER
- MAX SPL 119 dB
- FREQUENCY RESPONSE [-6dB]: 85 Hz - 20,000 Hz
- HF: 1x 0.75", 1" v.c. NEODYMIUM
- LF: 1x 6.5", 1.5" v.c. COAXIAL WOOFER
Specifications
Speaker Type
Passive 2-way Coaxial Speaker
Acoustical data
RMS Power
100 W
Peak Power
400 W
Frequency Response [-6 dB]
85 Hz - 20,000 Hz
Impedance
8 Ohm
Sensitivity 1W@m
93 dB
Max SPL
119 dB
HF
1x 0.75", 1" v.c. Neodymium
LF
1x 6.5", 1.5" v.c. Coaxial woofer
Dispersion
100x100°
X-Over Frequency
2100 Hz (internal X-Over)
Input
Connections
Screw terminal block (IN+ | IN- | OUT+ | OUT-)
Mechanics
Housing
Plywood, polyurea finish
Rigging points
2x M6 threaded nut
Accessories
bracket included
IP rating
IP 55
Width
195 mm (7.7 in)
Height
195 mm (7.7 in)
Depth
210 mm (8.3 in)
Weight
4.8 kg (10.6 lbs)
