Product Description
Community R2-xx-CTO 12-inch 3-Way Full-Range Speaker - Grey - Configured-To-Order
The powerful three-way R2 system features exceptional pattern control and vocal projection, delivering very high sensitivity and output levels. Community’s M200 mid-range compression driver and the deep, low flare rate mid-range horn produce legendary long distance vocal projection with vocal clarity and extremely low distortion. Wide bandwidth directivity control makes it the ideal choice for taming difficult acoustic environments or achieving precision coverage over long distances. The R2 is available in three symmetric and two asymmetric coverage patterns.
Features
- Included weather-resistant mounting yoke for easy mounting and aim
- EN54-24 Certified Models
- High-efficiency horn loading
- Application-specific coverage pattern
- High-fidelity, full-range reproduction of music and speech
- Weather-treated drivers and crossovers
Specs
- Transducers: LF 2 x 12” weather-treated cone; MF 1 x M200; HF - 1 x 1” exit titanium
- Operating Range: 70 Hz – 16 kHz
- Sensitivity (1W/1m): 106 dB
- Power Handling: 400 W continuous @ 4 ohms
- Continuous Max Output: 132 dB (138 dB Peak)
- Nominal Beamwidth (H x V): -52 (50° x 20°), -77 (70° x 70°), -94 (90° x 40°), -474 (40-70° x 40°), -694 (60-90° x 40°)
- Finish: Hand-laminated multilayer fiberglass with paintable, light grey gel coat and dual-layer powder-coated steel grille
- Dimensions (H x W x D): 24.8" x 24.8" x 30.8" (629 x 629 x 781 mm)
