Its color wheel has seven selected colors + open: dark red, brilliant blue, dark green, golden amber, dark orange and navy blue. There is also a 3200K CTO filter on the color wheel, which produces a very natural warm white. The gobo wheel consists of seven fully interchangeable HD gobos and a four-faced rotating prism enhances the effects section. The 5° soft-edge frost filter also allows diffuse blurring right up to a wash-like effect.

The zoom with autofocus ranges from 13° to 43°, which is truly remarkable for a spotlight of this size. The 24-bit electronic dimmer provides a choice of four curves. Thanks to its compactness and light weight, the pan and tilt movements can be driven at exceptionally high speed and used to create exciting moving light effects.

With its outstanding cost-performance ratio, the extraordinarily lightweight, compact, versatile Mini-B Spot is the ideal fixture for any rental company. It is also bound to become extremely popular in the installation and cruise ship markets, where versatile, small fixtures with a big punch are sought after.

Features

• Light source: 70W white LED engine
• Extremely compact and lightweight
• Highly efficient light output (3,500 lm)
• Very low power consumption (150W)
• Front Lens diameter: 60mm
• Motorized 13° to 43° zoom range
• Very high-speed pan and tilt movements
• 5° linear soft-edge frost
• 24-bit digital dimmer
• 7-color wheel: dark red, brilliant blue, dark green, golden amber, dark orange, navy blue, CTO + open
• 3200K CTO filter on the color wheel
• 7-gobo wheel featuring HD, interchangeable gobos
• Four-facet rotating prism
• Electronic strobe @ 25 f/sec
• Ethernet access
• 4 Operating modes: Constant – Auto – Silent – Theatre
• Control signal: USITT DMX 512. Protocols: RDM,WebServer, Art-Net and sACN
• DMX Channels: 18
• CloudIO Ready: fully compatible with CloudIO
• Operating voltage: 100-240V, 50/60 Hz
• Weight: 8.5 Kg (18.7 lbs)
• Size (LxWxH): 401x240x186mm (15.8”x9.4”x7.3”)

Specifications

Light Source Type

• 70W Custom White LED Engine
• CRI: 70+
• Colour Temperature: 7000K
• Lamp life expectancy: 20000 hrs
• *It may vary depending on various factors, as type of use and environment

Photometric Data

• Zoom range: 13° to 43°
• 3450 Lumen Output (Integrating Sphere)
• Front lens diameter: 60mm
• High efficiency optical system

Noise Level

• Theatre fan mode: 29.0 dBA
• Silent fan mode: 31.0 dBA
• Auto fan mode: 35.8 dBA
• Constant fan mode: 49.9 dBA

Control and Connections

• Personalities: Single mode with 19 control channels
• Control Protocol: DMX, Art-Net, RDM, sACN
• DMX and RDM connectors: Locking 5 pin XLR IN/THRU
• Ethernet port: RJ45 IN
• Power connector: PowerCon True1 IN/OUT
• Built In Web Server

Dynamic Effects

• Colours:
  • Fixed color wheel with 7 dichroic colors
• Gobos:
  • 1 Rotating gobo wheel with 7 HD Indexable and replaceable gobos
  • Ext diam. 15.9 mm
  • Image diam. 12.5 mm
  • Thickness 1.1 mm
• Frost:
  • Linear soft edge Frost 5°
• Rotating Effects:
  • 4 Facets prism with rotation in both direction at variable speed
• Movement:
  • Tilt: 270° - 16bit
  • Pan: 540° - 16bit
  • Automatic repositioning
  • Fast/Normal speed selectable by Function channel
• Beam:
  • Motorized Zoom and Focus
• Dimmer/Shutter:

  • High resolution electronic Dimmer - 24 bit, 4 curves
  • High speed electronic Shutter and Strobe

Hardware and Software

• Long life self-charging battery
• Display Graphic LCD backlit b/w Display
• Firmware upload from another fixture
• Firmware Upgrade via Web Server
• Diagnostic
• DMX monitoring
• Remote access through RDM
• CloudIO compatibility

Housing

• Aluminum and steel structure with plastic covers
• Two side handles for transportation
• IP20 protection rate

Working Position

• Working in any position
• Hanging system: with fast-lock omega clamps (1/4 turn) on the base
• Optional safety chain

Electrical

• Operating Voltage: 100-240V, 50/60 Hz - In/Out Max 16(8) fixtures @ 200-240Vac (@ 100-120Vac); Max 2200W; Max 10A
• Power Supply: Electronic auto range with active PFC
• Max Power consumption: 140VA

Thermal Specification

• Max ambient temperature 45°C (113°F)
• Min ambient temperature -20°C (-4°F)
• Max temperature of the external surface 90°C (194°F)
• Total heat dissipation: 478 BTU/hr ±10% / 504 kJ/hr ±10%

Safety Specs

• Minimum distance of illuminated objects 0.5 meters (1’ 8”)
• Minimum distance from flammable materials 0.2 meters (8”)
• Fuse T2.5A – 250V
• Thermally protected power supply (overheating and cooling failure)
• Forced ventilation with axial fans

Compliance

• CE: conforms to the European Directives
• UKCA: conforms to UK Regulations
• EAC: conforms to EurAseC Regulations
• cMETus Listed

Packaging

• Carton box + Polystyrene
• Carton box + Foam shell
• Flight case + Foam shell (8 positions)

Weight - Size

• 8.5 Kg (18.7 lbs)
• 220x186mm (base dimension) – 401mm with vertical head (h)
• Distance between two fixtures 400mm

Accessories

• Omega clamp: 1x 381014-801 (included)
• ETL Power cord 1.5mt. (bare end with IP65 PowerConTrue1 connector): CAB02B-802 (included)
• Foam shell: F21335/001 (optional)
• Flight-case for 8 Mini-B Spot: CF1019 without foam shell (optional)
• Flight-case for 8 Mini-B Spot: CF1019F with 8 foam shell (optional)
• Safety Chain: 105015-802 (optional)
• Clamp: C21070 (optional)
• Handles: CA3001000100 (optional)
