Claypaky focus of developing innovative and useful solutions for lighting take a bold new step with the development of the Claypaky Panify. The Panify allows you to take a static, non-moving fixture and turn it for dynamic effects.

The Panify is designed to accept not only Claypaky products such as the Tambora Batten or MINI-B PARLED AQUA, but most static lights from other brands that do not have the ability to pan. The Panify offers endless pan operation and various speeds and can accept fixtures up to 30 kilograms (66 pounds). When the load is 20 kilograms (44 pounds) or less, the unit can spin up to 50 RPM and when the load is greater than 20 kilograms, the unit can rotate the heavier loads up to 22 RPM to provide unparalleled effects.

The Panify has two power inputs – one input for the unit itself and the other for the mounted fixture. Because of the innovative design of the unit’s crossbeam, the power is routed from the enclosure to the crossbeam where the mounted fixture connects for its power and DMX; so, there are no concerns of tangled power or DMX cables when using the endless pan feature. The Panify only draws about 150 Watts of power and only requires a few channels of DMX to operate. The unit is already wireless DMX ready, so you do not have to run additional DMX cabling.

The Panify is not limited to fixtures and could be used to turn scenery, signs, screens and more. The unit is IP66 rated and can be used and hung in any position. The Panify expands and extends the usefulness of static fixtures or whatever you need to turn for your productions.  Its flexibility and versatility allow the Panify to be anything you need it to be.

Specifications

Control and Connections

• Personalities: Single mode with 5 control channels
• Control Protocol: DMX, Art-Net, RDM, sACN
• DMX and RDM connectors: Locking 5 pin XLR IN/THRU
• Ethernet port: RJ45 IN
• Power connector: PowerCon True1 IN/OUT
• Built In Web Server

Dynamic Effects

• Movement:
  • Pan Endless
  • Max applicable weight: 30Kg (with the weight of the fixture balanced on the Panify)
  • Max rotation speed: 43RPM

Hardware and Software

• Long life self-charging battery
• Display Graphic LCD backlit b/w Display
• Firmware upload from another fixture
• Firmware Upgrade via Web Server
• Diagnostic
• DMX monitoring
• Remote access through RDM
• CloudIO compatibility

Housing

• Aluminum and steel structure with plastic covers
• Two side handles for transportation
• IP66 protection rate

Working Position

• Working in any position
• Hanging system: with fast-lock omega clamps (1/4 turn) on the base
• Optional safety chain

Electrical

• Operating Voltage: 100-240V, 50/60 Hz
• Power Supply: Electronic auto range with active PFC
• Max Power consumption: 220VA
• Mains Out: 2300 VA @ 230V; 1250 VA @ 110V

Thermal Specification

• Max ambient temperature 45°C (113°F)
• Min ambient temperature -20°C (-4°F)

Safety Specs

• Fuse 4A – 250V
• Forced ventilation with axial fans

Compliance

• CE: conforms to the European Directives
• UKCA: conforms to UK Regulations
• EAC: conforms to EurAseC Regulations
• cMETus Listed

Packaging

• Carton box + Polystyrene
• Flight case + Foam shell (4 position)
• Distance between two fixtures: Depending from installed product.)

Weight - Size

• 13.8 Kg (30.4 lbs)
• 390.8mm x 295mm x 252.8mm

Accessories

• ETL Mains cable, 1.5mt. (Bare Ends / IP65 PowerConTrue1 connector): CAB02B-802 (included)
• Omega bracket: 2x 183102/805 (included)
• Power cables 0.5mt.: 2x CAB0PR/801 (included)
• DMX cable 0.5mt.: CAB0PS/801 (included)
• Safety chains 0.5mt.: 2x FUN00C/001 (included)
• Screws/Bolts/Washers: 4x418100-801 (included)
• Clamp: C21070 (optional)
• Safety chain: 105041-003 (optional)
• Power Con True1 connector: CON00O (optional)
• Foam shell: F21329/001 (optional)
• Flight case 4 pos.: CF1016 (optional)
• Universal bracket: CA3017000102 (optional)
