The B-EYE is first and foremost an excellent quality wash light. It is able to wash surfaces with colors at any distance, making the most of its light source. B-EYE is brighter than any LED-wash with the same rated power, thanks to its special optical unit with a truly amazing lumen/watt ratio, designed and built by Claypaky. The zoom ranges from 4° to 60° and it is therefore suitable both for environments with low ceilings (small theatres and TV studios, for example), where large angles are extremely useful, and for shows in arenas or large environments, where a tight zoom is perfect.
When the B-EYE beam is zoomed down to 4°, the “wash” light turns into a “beam” fixture. The B-EYE therefore becomes a surprising mid-air parallel effect light, capable of generating a pulsating beam of micro-rays, which may be controlled individually, each with its own colors and shades. All the parameters of each LED can be completely controlled.
Lastly, the B-EYE K20 introduces a completely new feature: the front lens may be rotated to create lots of small bright compositions, which may be opened and closed like petals. By adding colors and dynamic graphics, the B-EYE generates never-seen-before graphic light effects

Features

• Light Source

  37 x 15W RGBW LEDs
• Zoom range

  4°-60° Electronic Zoom Range
• Effects

  Three operating modes: wash, beam, FX (Kaleido effects); Rotating Front Lens; 0-100% linear electronic dimmer; Adjustable speed stop/strobe effect; dedicated CTC dedicated

Specifications

Light Source Type

• 37 Osram Ostar RGBW LEDs
• LED Nominal Wattage: 15W
• LED Average Life: 50,000 h
  *It may vary depending on various factors, as type of use and environment

Optics

• 4°-60° Electronic Zoom Range
• High efficiency optical system

Input Power

• 750 VA @230Vac - 50Hz

Control and Connections

• Control channels: 21/35/111/148
• Basic Engine (Standard and Shape Mode).
• Pixel Engine (RGB and RGBW Mode).
• DMX protocol signal: USITT DMX 512.
• Art-Net / RDM / sACN
• Display: Graphic LCD backlit b/w Display.
• Pan/Tilt Resolution: 16 bit.
• Dimmer Resolution: 16 bit.
• Movement control: vectorial.
• DMX signal connection: 3 and 5 pole XLR input and output.
• Software upload through DMX input

Effects Section

• Three operating modes: wash, beam, FX (Kaleido effects)
• Bi-directional Rotating Front Lens
• Digital Wash-Beam Framing effect
• Beam edge softening control (in Wash mode)
• Pixel Patterning Macros with enhanced control
• 0-100% linear electronic dimmer
• Adjustable speed stop/strobe effect, with instantaneous blackout
• Dedicated channel for color temperature setting
• White CT Emulation 2500-8000K
• RGBW auto-tuning to lamp CT Emulation
• Tungsten Lamp Emulation
• Slow Strobe: 1 flash/sec; Fast Strobe: 25 flash/sec
• Movement: - PAN = 540°- TILT = 210°

Hardware and Software

• Long-life auto-charging buffer battery
• Preset color and graphic effect macros
• Function reset controllable from a central control unit
• Menu-driven internal self-test function
• Ethernet ready with RJ45 socket
• Display: backlit black-and-white graphic LCD display
• Electronic check-up of every single parameter with error alarm
• DMX level monitoring on each channel
• Automatic internal data transmission error diagnostics
• Firmware upgrade even when the unit is not connected to the power supply
• Firmware transfer from one light to another

Housing

• Aluminium structure with die-cast plastic cover
• Two side handles for transportation
• PAN lock for transport and maintenance

Working Position

• Working in any position
• Hanging system: with fast-lock omega clamps (1/4 turn) on the base

Electrical

• Power Supply: 100-240V 50/60Hz
• 750 VA @230Vac - 50Hz
• Max Power consumption: 750 VA

Safety Specs

• Thermally protected power supply (overheating and cooling failure)
• Forced ventilation with axial fans

Compliance

• In conformity with the European Directives:
• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
• 2014/30/EU - Electromagnetic Compatibility (EMC)
• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
• 2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
• ETL This product it is available, on demand, with cETLus Listed Mark, that complies with the UL 1573, UL 8750 and CSA C22.2 No. 166
  standards.

Packaging

• Carton box + Polystyrene
• Carton box + Foam shell
• Flight case + Foam shell (2 positions)

Weight

• 21 Kg (46.3 lbs)

Accessories

• Omega clamps: 2x183102/805 (included)
• Power cord: CAB03E/802 (included)
• Foam shell: F21313/001 (optional)
• Flight case 2 positions: CF1001 (optional)
• Safety Chain: 105041/003 (optional)
