Product Description
Chauvet Pro COLORdash PAR H18X RGBWA+UV LED Wash Light
Key Features
- 18 x RGBWA+UV LEDs, 150W for Color Wash
- Color Temperature: 2800 to 10,000K
- 0 to 100% Dimming with Selectable Curves
- 23.6° Beam Angle / 38.6° Field Angle
- DMX Channel Modes: 6, 8, 9, 13, or 14
- Variable Color-Strobe Effect
- Built-In Automated Programs
- Double-Bracket Yoke/Floor Stand
- Universal Autosensing Power Supply
- Includes Gel-Frame Holder
Overview
Lighting designers in search of a quality wash light will be impressed with the CHAUVET PROFESSIONAL COLORdash PAR H18X, a hex-colored LED wash light designed to produce color washes with variations of white and smooth color mixing, devoid of multicolored shadows. Featuring 18 RGBWA+UV LEDs (red, green, blue, white, amber, and ultraviolet) and an 23.6° beam angle, it is well suited for venue uplighting, dancefloor color washing, stage illumination, and more.
The COLORdash PAR H18X can be used as a standalone with dynamic effects including electronic dimming, color macros, variable strobe, built-in automated programs, and color-temperature presets. It can also be controlled via DMX or used in a primary/secondary configuration to coordinate multiple fixtures without the need for a controller. The fixture comes equipped with an LED display, an autoranging power supply, and a double-bracket yoke, which can be used for conventional mounting to a truss or as a variable-angle floor stand. The COLORdash PAR H18X ships with a gel-frame holder.
Specifications
| Fixture Type | PAR |
| Light Source | 18 x Color LED - 150 W / 550 mA |
| Light Source Life Expectancy | 50,000 Hours |
| Colors | Red Green Blue White Amber Ultraviolet |
| Photometrics | 112.1 fc / 1207 Lux at 16.4' / 5 m |
| Color Temperature | 2800 to 10,000K |
| Lumen Output | 5736 Lumens |
| Beam Angle | 23.6° |
| Field Angle | 38.6° |
| Shutter / Strobe | Electronic |
| Zoom Adjustment | None |
| Dimming | Electronic, 0 to 100% |
| Operating Modes | DMX |
| Macros / Programs | Color Mixing Color Temperature Auto-Program Color Fade |
| Effects | Strobe |
| Strobe Rate | 0 to 20 Hz |
| Gobos | None |
| Control Protocols | DMX512 |
| DMX Channel Modes | 5 Mode(s): 6 / 8 / 9 / 13 / 14-Channel |
| Display / Controls | OLED / 4-Button |
| Remote Control | None |
| Mobile App Compatible | No *As of December, 2022: Check with manufacturer for the most up-to-date compatibility |
| Inputs/Outputs | 1 x XLR 3-Pin DMX Input 1 x XLR 3-Pin DMX Output 1 x XLR 5-Pin DMX Input 1 x XLR 5-Pin DMX Output |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| AC Power Connector | Input: powerCON Output: powerCON Plug Type: NEMA 5-15 Cord Length: 5' / 1.5 m |
| Power / Current Consumption | 120 VAC, 60 Hz: 155 W / 1.3 A 208 VAC, 50 Hz: 153 W / 0.77 A 230 VAC, 50 Hz: 152 W / 0.7 A |
| Power Linking | 9 Units at 120 VAC 15 Units at 208 VAC 17 Units at 230 VAC |
| IP Rating | IP20 |
| Mounting | Omega Bracket |
| Included Accessories | 1 x Power Cable 1 x Gel Frame |
| Duty Cycle | None |
| Exterior Color | Black |
| Cooling | Convection |
| Certifications | CE, MET, FCC, UKCA *as per Manufacturer |
| Dimensions | 12.45 x 8.68 x 4.38" / 31.62 x 22.05 x 11.13 cm |
| Weight | 10.4 lb / 4.7 kg |
