Product Description
Chauvet DJ SWARM5FXILS Swarm 5 FX ILS 3-in-1 Multi-Effects with Derby, Lasers, and Strobe
Overview
Lighting designers and mobile entertainers in search of a multi-effect lighting fixture will be impressed with the Chauvet Swarm 5 FX ILS, a 3-in-1 fixture, well suited for lighting installations and live performance applications such as DJing at parties and in clubs. The fixture includes an RGBAW rotating derby, a red and green laser, and a white strobe effect to create a complex dynamic lighting display.
The Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced, coordinated light show across multiple fixture types, allowing any ILS-enabled fixer to be controlled wired or wirelessly. The Swarm 5 FX ILS provides separate control over both color and programs—use built-in automated programs, sound-activated programs via built-in microphone, master/slave mode, or DMX512 control mode over XLR connectors. Multiple units can be power-linked together to save on cabling.
Features
- Integrated Lighting System (ILS)
- RGBAW Rotating Derby
- Red and Green Laser
- White Strobe Effect
- Separate Color and Program Control
- Digital Display for Navigating Programs
- Automated and Sound Activated Programs
- Master/Slave and DMX-512 Control
- Power Link Multiple Units Together
- Fits CHS-40 Gear Bag (Sold Separately)
Specifications
| Fixture Type | Special Design |
| Light Source | 5 x Color LED - 3 W / 300 mA 8 x White LED - 1 W / 300 mA 1 x Laser Diode - 100 mW 1 x Laser Diode - 30 mW |
| Expected Lamp Life | 50,000 Hours |
| Colors | Red, Green, Blue, Amber, White |
| Laser | Green: 520 nm / 30 mW Red: 650 nm / 100 mW |
| Photometrics | 77 fc / 823 Lux at 6.5' / 2 m |
| Coverage Angle | 100° (Laser) 65° (Swarm) |
| Beam Angle | 17° (Strobe) |
| Field Angle | 35° (Strobe) |
| Shutter / Strobe | Electronic |
| Operating Modes | DMX, Primary/Secondary, Sound-Active, Standalone |
| Macros / Programs | Auto-Program Strobe Effect Macro Color Macro |
| Effects | Strobe |
| Strobe Rate | 0 to 20 Hz |
| Gobos | None |
| Control Protocols | DMX512 |
| DMX Channel Modes | 1 Mode(s): 9-Channel |
| Display / Controls | LED / 4-Button |
| Remote Control | None |
| Inputs/Outputs | 1 x XLR 3-Pin DMX Input 1 x XLR 3-Pin DMX Output |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| AC Power Connector | Input: 1 x IEC Output: 1 x Edison |
| Power / Current Consumption | 120 VAC, 60 Hz: 62 W / 0.5 A 230 VAC, 50 Hz: 66 W / 0.3 A |
| Power Linking | 15 Units at 120 VAC 26 Units at 230 VAC |
| Environmental Protection | None |
| Mounting | Single Yoke Only |
| Included Accessories | 1 x Power Cable |
| Duty Cycle | None |
| Exterior Color | Black |
| Cooling | Convection |
| Certifications | CE, RoHS, *as per Manufacturer |
| Dimensions | 9.75 x 11.7 x 12.2" / 248 x 298 x 310 mm |
| Weight | 9.8 lb / 4.5 kg |
