Product Description

Chauvet DJ BUNDLE 7 COLORband T3BT ILS (4), Swarm 5 FX ILS (1), D-FI USB 4PK (1)

Overview

COLORband T3BT ILS (4)

Create amazing, automated effects with the COLORband T3BT ILS. This tri-color (RGB) linear wash light has 3 zones of control that create dynamic, considered light shows. Control your setup directly from your phone with built-in Bluetooth technology. Also, enjoy the latest in lighting control technology with the Integrated Lighting System. Thanks to ILS, you can program and control your setup to create synchronized lightshows across different fixtures in no time. Take charge of your lighting with the COLORband T3BT ILS. Fits best in the CHS-60 VIP Gear Bag.

Features

• Full-size linear wash light with built-in Bluetooth® wireless technology

• ILS compatibility for use in the ILS ecosystem

• D-Fi USB compatibility for wireless master/slave or DMX control

• Control directly from a smart phone or tablet without any additional hardware

• 3 zones of control create amazing, automated effects

• Easily set static colors or automated programs with the optional IRC-6 remote

• Save time running cables and extension cords by power linking multiple units

• Fits best in the CHS-60 VIP Gear Bag

Specifications

• DMX Channels:3, 5 or 13
• DMX Connectors:3-pin XLR
• Light Source:12 LEDs (tri-color RGB), 3 W (1 A) 50,000 hours life expectancy
• Strobe Rate:0 to 25 Hz
• Beam Angle:53°
• Operating Frequency:2.4GHz
• Coverage Angle:112°
• Illuminance:433 lux @ 2 m
• Power Linking:13 units @ 120 V; 24 units @ 230 V
• Input Voltage:100 bis 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:
  43 W, 0.6 A @ 120 V, 60 Hz
  41 W, 0.3 A @ 230 V, 50 Hz
• Weight:6.6 lb (3 kg)
• Size:39.3 x 3.8 x 5.5 in (1000 x 98 x 140 mm)
• Approvals:CE, RoHS, UKCA, FCC
• Optional Controllers: IRC-6
• Bluetooth version: 4.2
• Max Unobstructed Distance: 150 ft (45.7 m)

Swarm 5 FX ILS (1)

Your parties deserve the excitement of Swarm 5 FX ILS. This 3-in-1 LED light that includes an RGBAW rotating derby, red/green laser, and white strobe effect and compatibility with ILS that makes creating coordinated light shows across different fixture types easy. Swarm 5 FX ILS also features D-Fi USB compatibility for wireless Master/Slave or DMX control. Flexibility is even greater with automated and sound-activated programs, or Master/Slave and DMX modes and separate color and program control.

Features

• 3-in-1 LED light that includes an RGBAW rotating derby, red/green laser, and white strobe effect

• ILS compatibility for use in the ILS ecosystem

• D-Fi USB compatibility for wireless Master/Slave or DMX control

• Laser projects thousands of red and green laser beams

• Operation allows for separate color and program control

• Increase control options using automated and sound-activated programs, or Master/Slave and DMX modes

• Save time running cables and extension cords by power linking multiple units

• Fits best inside the CHS-40 VIP gear bag

Specifications

• DMX Channels:9
• DMX Connectors:3-pin XLR
• Light Source:(Swarm): 5 LEDs (1 red, 1 green, 1 blue, 1 amber, 1 white) 3 W, (300 mA), 50,000 hours life expectancy
  (strobe): 8 LEDs (white) 1 W, (300 mA), 50,000 hours life expectancy
  (laser): 520 nm/30 mW (green) laser diode, 650 nm/100 mW (red) laser diode
• Strobe Rate:0 to 20 Hz
• Beam Angle:(strobe): 17°
• Field Angle:(strobe): 35°
• Coverage Angle:(laser): 100°
  (Swarm): 65°
• Illuminance:(strobe): 823 lux @ 2 m
• Power Linking:15 units @ 120 V; 26 units @ 230 V
• Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:62 W, 0.5 A @ 120 V, 60 Hz
  62 W, 0.3 A @ 230 V, 50 Hz
• Weight:9.8 lb (4.5 kg)
• Size:9.75 x 11.7 x 12.2 in (248 x 298 x 310 mm)
• Approvals:CE, FDA, RoHS, UKCA
• Classified per EN/IEC 60825-
• Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 56, dated May 8, 2019

D-Fi USB (1)

CHAUVET DJ has developed a series of fixtures that include a standard USB connection. You can now wirelessly connect to all of them using the new D-Fi USB transceiver, which eliminates the need for any DMX cables. The USB transceiver is powered directly from the fixture. Control your USB fixtures using any of our wireless controllers, or from your smartphone with the D-Fi Hub and FlareCON.

Features

• Finger-sized wireless D-Fi transceiver provides instant wireless communication

• Transfers DMX as well as master/slave signals between similar fixtures

• Eliminates the need for DMX cables

• Plugs directly into USB-compatible devices

• Works without the need of an external power supply

• Fully FCC/RTTE compliant

Specificiations

• Weight:1.1 oz. (31.2 g)
• Size:3 x 0.9 x 0.5 in (78 x 25 x 13 mm)
• Approvals:CE, FCC
• Operating Frequency:: 2.412 to 2.484 GHz

This Bundle Includes

COLORband T3BT ILS, Quantity 4

Swarm 5 FX ILS, Quantity 1

D-FI USB 4PK, Quantity 1

D-Fi USB, Quantity 1
