  • ChamSys CHAMMMSDI2 MediaMaster Vision-SDI2 PCIe Card (2 SDI Inputs/Loop Outputs) (CHAMMMSDI2)

    • ChamSys CHAMMMSDI2 MediaMaster Vision-SDI2 PCIe Card (2 SDI Inputs/Loop Outputs)

    MSRP: $4,125.00
    $3,715.00
    (You save $410.00 )
    SKU:
    CHAMMMSDI2
    UPC:
    781462231255
    Availability:
    Typically ships in 3-5 business days.
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    ChamSys CHAMMMSDI2 MediaMaster Vision-SDI2 PCIe Card (2 SDI Inputs/Loop Outputs)

    Overview

    Add dual SDI input to your MediaMaster VS2+ or VS4+ system with the MediaMaster Vision-SDI2 PCIe Card from ChamSys. This PCIe card allows you to add two 3G-SDI inputs to the system using a standard PCIe slot for use with MediaMaster software. The card also features two SDI loop outputs. It supports SD/HD/3G-SDI formats, up to 2048 x 1556 capture resolution, and a bus data rate up to 650 MB/s.

    Features

    • Add 2 x 3G-SDI Inputs to VS2+/VS4+
    • Import SDI Video into MediaMaster
    • 2 x 3G-SDI Loop Outputs
    • 650 MB/s Bus Data Rate
    • Maximum 2048 x 1556 Capture Resolution
    • SD-SDI, HD-SDI, and 3G-SDI Support

    Specifications

    General
    Compatibility
    CHAUVET Professional MediaMaster VS4+ / MediaMaster VS2+
    Type
    PCIe, Half Size Card
    Maximum Resolution
    2048 x 1556
    Buffer
    Frame Buffer Memory: 64 MB per Channel (Total 128 MB)
    Inputs/Outputs
    Video I/O
    2x BNC (3G-SDI) Input ( SD/HD/3G-SDI )
    2x BNC (3G-SDI) Output ( SD/HD/3G-SDI )
    Power
    Power Source
    Proprietary Interface
    DC Input Power
    3.3 to 12 VDC at 0.45 to 0.85 A
    Power Consumption
    12 W
    Physical
    Operating Conditions
    32 to 95°F / 0 to 35°C at 5 to 90% Humidity
    Storage Conditions
    -4 to 158°F / -20 to 70°C at 5 to 90% Humidity
    Dimensions
    6.7 x 4.3" / 170 x 110 mm

    Other Details

    All products except consumables and input devices, are covered by our own 24 month return to base warranty. If you wish to return any faulty item you must first contact our Support Department and obtain a RMA Number. The warranty is non-transferable. Any warranties for defects shall become void if the Seller’s operating and maintenance instructions are not complied with, if modifications are made to the goods delivered, or if replacement parts or consumables are used that do not meet the original specifications.
